630W5W Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB RCPT 5POS R/A SLDR
| Part | Color | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Voltage Rating | Dielectric Material | Contact Finish | Shell Material, Finish | Number of Rows [custom] | Ingress Protection | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Contact Type | Material Flammability Rating | Shell Size, Connector Layout | Shell Size, Connector Layout | Flange Feature | Connector Style | Number of Positions | Connector Type | Features | Current Rating (Amps) | Termination | Flange Feature | Shell Size, Connector Layout [x] | Shell Size, Connector Layout [custom] | Number of Rows | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | Gold | Nickel Plated Steel | 2 | IP67 - Dust Tight Waterproof | 0.38 µm | 15 µin | Panel Mount Right Angle Through Hole | Signal and Power | UL94 V-0 | 1 | 5W1 DE E | Housing/Shell (M3) | Combo D-Sub | 5 | Receptacle Female Sockets | Shielded | 5 A 30 A | Solder | |||||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | Gold | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 0.127 µm | 5 µin | Panel Mount Right Angle Through Hole | Power | UL94 V-0 | 5W5 | Housing/Shell | Combo D-Sub | 5 | Receptacle Female Sockets | Mounting Brackets Shielded | 20 A | Solder | 4-40 | 3 | DB B | 1 | |||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | Gold | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 0.127 µm | 5 µin | Panel Mount Right Angle Through Hole | Power | UL94 V-0 | 5W5 | Housing/Shell (M3) | Combo D-Sub | 5 | Receptacle Female Sockets | Shielded | 10 A | Solder | 3 | DB B | 1 | ||||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | Gold | Nickel Plated Steel | 2 | IP67 - Dust Tight Waterproof | 0.127 µm | 5 µin | Panel Mount Right Angle Through Hole | Signal and Power | UL94 V-0 | 1 | 5W1 DE E | Housing/Shell (M3) | Combo D-Sub | 5 | Receptacle Female Sockets | Board Lock Mounting Brackets Shielded | 5 A 30 A | Solder | |||||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | Gold | Nickel Plated Steel | 2 | IP67 - Dust Tight Waterproof | Panel Mount Right Angle Through Hole | Signal and Power | UL94 V-0 | 1 | 5W1 DE E | Housing/Shell | Combo D-Sub | 5 | Receptacle Female Sockets | Mounting Brackets Shielded | 5 A 30 A | Solder | 4-40 | Flash | |||||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | Gold | Nickel Plated Steel | 2 | IP67 - Dust Tight Waterproof | 0.127 µm | 5 µin | Right Angle Through Hole | Signal and Power | UL94 V-0 | 1 | 5W1 DE E | Housing/Shell (M3) | Combo D-Sub | 5 | Receptacle Female Sockets | Mounting Brackets Shielded | 5 A 30 A | Solder | |||||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | Gold | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 0.38 µm | 15 µin | Panel Mount Right Angle Through Hole | Power | UL94 V-0 | 5W5 | Housing/Shell (M3) | Combo D-Sub | 5 | Receptacle Female Sockets | Board Lock Mounting Brackets Shielded | 20 A | Solder | 3 | DB B | 1 | ||||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | Gold | Nickel Plated Steel | IP67 - Dust Tight Waterproof | 0.38 µm | 15 µin | Panel Mount Right Angle Through Hole | Power | UL94 V-0 | 5W5 | Housing/Shell | Combo D-Sub | 5 | Receptacle Female Sockets | Shielded | 40 A | Solder | 4-40 | 3 | DB B | 1 | |||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | Gold | Nickel Plated Steel | 2 | IP67 - Dust Tight Waterproof | 0.38 µm | 15 µin | Right Angle Through Hole | Signal and Power | UL94 V-0 | 1 | 5W1 DE E | Housing/Shell (M3) | Combo D-Sub | 5 | Receptacle Female Sockets | Mounting Brackets Shielded | 5 A 30 A | Solder | |||||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | Gold | Nickel Plated Steel | 2 | IP67 - Dust Tight Waterproof | 0.127 µm | 5 µin | Panel Mount Right Angle Through Hole | Signal and Power | UL94 V-0 | 1 | 5W1 DE E | Housing/Shell (M3) | Combo D-Sub | 5 | Receptacle Female Sockets | Board Lock Mounting Brackets Shielded | 5 A 40 A | Solder |
