M55-701 Series

Catalog

CONNECTOR, HEADER, 80POS, 2ROW, 1.27MM

Part	Number of Rows [custom]	Shrouding	Contact Finish - Mating	Number of Positions Loaded	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Connector Type	Contact Finish - Post	Termination	Fastening Type	Features	Insulation Material	Contact Material	Pitch - Mating	Pitch - Mating	Current Rating (Amps)	Insulation Color	Contact Type	Row Spacing - Mating	Row Spacing - Mating	Number of Positions	Contact Length - Mating	Contact Length - Mating	Contact Shape	Material Flammability Rating	Operating Temperature [Min]	Operating Temperature [Max]	Insulation Height	Insulation Height	Mounting Type	Applications	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Mated Stacking Heights
Harwin Inc. M55-7018042R	2	Shrouded - 4 Wall	Gold	All	0.025 µm	1 µin	Header	Tin	Solder	Latch Lock	Board Guide Pick and Place Solder Retention	Liquid Crystal Polymer (LCP)	Phosphor Bronze	1.27 mm	0.05 in	1.2 A	Black	Male Pin	0.05 in	1.27 mm	80	4 mm	0.157 in	Rectangular	UL94 V-0	-55 C	125 °C	0.325 in	8.25 mm	Surface Mount	Automotive General Purpose Industrial	2.54 µm	100 µin	9.5 mm 12.3 mm 16.9 mm
Harwin Inc. M55-7011642R	2	Shrouded - 4 Wall	Gold	All	0.025 µm	1 µin	Header	Tin	Solder	Latch Lock	Board Guide Pick and Place Solder Retention	Liquid Crystal Polymer (LCP)	Phosphor Bronze	1.27 mm	0.05 in	1.2 A	Black	Male Pin	0.05 in	1.27 mm	16	4 mm	0.157 in	Rectangular	UL94 V-0	-55 C	125 °C	0.325 in	8.25 mm	Surface Mount	Automotive General Purpose Industrial	2.54 µm	100 µin	9.5 mm 12.3 mm 16.9 mm
Harwin Inc. M55-7012042R	2	Shrouded - 4 Wall	Gold	All	0.025 µm	1 µin	Header	Tin	Solder	Latch Lock	Board Guide Pick and Place Solder Retention	Liquid Crystal Polymer (LCP)	Phosphor Bronze	1.27 mm	0.05 in	1.2 A	Black	Male Pin	0.05 in	1.27 mm	20	4 mm	0.157 in	Rectangular	UL94 V-0	-55 C	125 °C	0.325 in	8.25 mm	Surface Mount	Automotive General Purpose Industrial	2.54 µm	100 µin	9.5 mm 12.3 mm 16.9 mm
Harwin Inc. M55-7016842R	2	Shrouded - 4 Wall	Gold	All	0.025 µm	1 µin	Header	Tin	Solder	Latch Lock	Board Guide Pick and Place Solder Retention	Liquid Crystal Polymer (LCP)	Phosphor Bronze	1.27 mm	0.05 in	1.2 A	Black	Male Pin	0.05 in	1.27 mm	68 positions	4 mm	0.157 in	Rectangular	UL94 V-0	-55 C	125 °C	0.325 in	8.25 mm	Surface Mount	Automotive General Purpose Industrial	2.54 µm	100 µin	9.5 mm 12.3 mm 16.9 mm
Harwin Inc. M55-7012642R	2	Shrouded - 4 Wall	Gold	All	0.025 µm	1 µin	Header	Tin	Solder	Latch Lock	Board Guide Pick and Place Solder Retention	Liquid Crystal Polymer (LCP)	Phosphor Bronze	1.27 mm	0.05 in	1.2 A	Black	Male Pin	0.05 in	1.27 mm	26	4 mm	0.157 in	Rectangular	UL94 V-0	-55 C	125 °C	0.325 in	8.25 mm	Surface Mount	Automotive General Purpose Industrial	2.54 µm	100 µin	9.5 mm 12.3 mm 16.9 mm
Harwin Inc. M55-7011242R	2	Shrouded - 4 Wall	Gold	All	0.025 µm	1 µin	Header	Tin	Solder	Latch Lock	Board Guide Pick and Place Solder Retention	Liquid Crystal Polymer (LCP)	Phosphor Bronze	1.27 mm	0.05 in	1.2 A	Black	Male Pin	0.05 in	1.27 mm	12	4 mm	0.157 in	Rectangular	UL94 V-0	-55 C	125 °C	0.325 in	8.25 mm	Surface Mount	Automotive General Purpose Industrial	2.54 µm	100 µin	9.5 mm 12.3 mm 16.9 mm
