CONN HEADER VERT 29POS 2.54MM

...

Part	Connector Type	Contact Length - Post	Contact Length - Post	Fastening Type	Number of Positions Loaded	Operating Temperature [Min]	Operating Temperature [Max]	Number of Rows	Contact Material	Contact Shape	Number of Positions	Insulation Material	Insulation Color	Shrouding	Current Rating (Amps)	Voltage Rating	Pitch - Mating	Pitch - Mating	Insulation Height	Insulation Height	Termination	Contact Finish - Post	Material Flammability Rating	Mounting Type	Contact Length - Mating	Contact Length - Mating	Contact Type	Contact Length - Post [custom]	Overall Contact Length	Overall Contact Length	Contact Length - Post [x]	Contact Length - Post [x]
Preci-Dip 800-80-029-10-002101	Header	0.118 in	3 mm	Push-Pull	All	-55 C	125 °C	1	Brass	Circular	29	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Black	Unshrouded	3 A	150 VDC	0.1 "	2.54 mm	0.116 "	2.95 mm	Solder	Tin	UL94 V-0	Through Hole	0.141 in	3.6 mm	Male Pin
Preci-Dip 800-80-037-65-001101	Header		2.79 mm	Push-Pull	All	-55 C	125 °C	1	Bronze	Circular	37	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Black	Unshrouded	3 A	150 VDC	0.1 "	2.54 mm	0.116 "	2.95 mm	Press-Fit Solder	Tin	UL94 V-0	Through Hole	0.191 in	4.85 mm	Male Pin	0.11 in	10.85 mm	0.427 in
Preci-Dip 800-80-052-20-004101	Header			Push-Pull	All	-55 C	125 °C	1	Brass	Circular	52	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Black	Unshrouded	3 A	150 VDC	0.1 "	2.54 mm	0.1 in	2.54 mm	Solder	Tin	UL94 V-0	Right Angle Through Hole	0.195 in	4.95 mm	Male Pin				0.126 "	3.2 mm
Preci-Dip 800-80-030-66-001101	Header			Push-Pull	All	-55 C	125 °C	1	Bronze	Circular	30	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Black	Unshrouded	3 A	150 VDC	0.1 "	2.54 mm	0.116 "	2.95 mm	Press-Fit Solder	Tin	UL94 V-0	Through Hole	0.191 in	4.85 mm	Male Pin		11.85 mm	0.467 in	0.15 in	3.81 mm
Preci-Dip 800-80-007-30-001101	Header			Push-Pull	All	-55 C	125 °C	1	Brass	Circular	7	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Black	Unshrouded	3 A	150 VDC	0.1 "	2.54 mm	0.116 "	2.95 mm	Solder	Tin	UL94 V-0	Surface Mount	0.191 in	4.85 mm	Male Pin
Preci-Dip 800-80-008-65-001101	Header		2.79 mm	Push-Pull	All	-55 C	125 °C	1	Bronze	Circular	8	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Black	Unshrouded	3 A	150 VDC	0.1 "	2.54 mm	0.116 "	2.95 mm	Press-Fit Solder	Tin	UL94 V-0	Through Hole	0.191 in	4.85 mm	Male Pin	0.11 in	10.85 mm	0.427 in
Preci-Dip 800-80-042-10-001101	Header	0.121 in	3.08 mm	Push-Pull	All	-55 C	125 °C	1	Brass	Circular	42	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Black	Unshrouded	3 A	150 VDC	0.1 "	2.54 mm	0.116 "	2.95 mm	Solder	Tin	UL94 V-0	Through Hole	0.191 in	4.85 mm	Male Pin		11.12 mm	0.438 in
Preci-Dip 800-80-018-10-001101	Header	0.121 in	3.08 mm	Push-Pull	All	-55 C	125 °C	1	Brass	Circular	18	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Black	Unshrouded	3 A	150 VDC	0.1 "	2.54 mm	0.116 "	2.95 mm	Solder	Tin	UL94 V-0	Through Hole	0.191 in	4.85 mm	Male Pin		11.12 mm	0.438 in
Preci-Dip 800-80-019-30-480101	Header			Push-Pull	All	-55 C	125 °C	1	Brass	Circular	19	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Black	Unshrouded	3 A	150 VDC	0.1 "	2.54 mm			Solder	Tin	UL94 V-0	Surface Mount	0.141 in	3.6 mm	Male Pin
Preci-Dip 800-80-062-10-002101	Header	0.118 in	3 mm	Push-Pull	All	-55 C	125 °C	1	Brass	Circular	62	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Black	Unshrouded	3 A	150 VDC	0.1 "	2.54 mm	0.116 "	2.95 mm	Solder	Tin	UL94 V-0	Through Hole	0.141 in	3.6 mm	Male Pin
