9154 Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 2CON 20AWG BEIGE SHLD
| Part | Shield Material | Shield Coverage | Number of Conductors | Length | Length | Jacket (Insulation) Material | Jacket Color | Conductor Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Usage | Operating Temperature [Max] | Operating Temperature [Min] | Voltage | Conductor Strand [custom] | Conductor Strand [custom] | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Cable Type | Conductor Insulation | Ratings | Shield Type | Features | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Aluminum | 100 % | 2 | 152.4 m | 500 ft | Poly-Vinyl Chloride (PVC) | Beige | Copper Tinned | 5.03 mm | 0.198 in | Audio Control Instrumentation | 80 °C | -20 ░C | 300 VDC | 28 AWG | 7 | 0.031 in | 0.787 mm | Multi-Conductor | Poly-Vinyl Chloride (PVC) | UL Style 2464 | Foil | Drain Wire | 20 AWG |
 Belden Inc. | Aluminum | 100 % | 2 | 304.8 m | 1000 ft | Poly-Vinyl Chloride (PVC) | Beige | Copper Tinned | 5.03 mm | 0.198 in | Audio Control Instrumentation | 80 °C | -20 ░C | 300 VDC | 28 AWG | 7 | 0.031 in | 0.787 mm | Multi-Conductor | Poly-Vinyl Chloride (PVC) | UL Style 2464 | Foil | Drain Wire | 20 AWG |
