MF80252V1 Series
Manufacturer: Sunon Fans
Beta
⌘K
FAN AXIAL 80X25MM 24VDC WIRE
| Part | Current Rating (Amps) | Material - Blade | Lifetime @ Temp. | Size / Dimension [z] | Size / Dimension [x] | Approval Agency | Operating Temperature [Max] | Operating Temperature [Min] | Features | Noise | Fan Type | Voltage - Rated | Weight | Weight | Width [y] | Static Pressure | Static Pressure | Air Flow | Air Flow | RPM | Termination | Bearing Type | Power (Watts) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sunon Fans | 0.065 A | Polybutylene Terephthalate (PBT) | 70000 Hrs | 80 mm | 80 mm | cURus TUV | 70 °C | -10 °C | Auto Restart | 33 dB(A) | Tubeaxial | 24 VDC | 0.167 lb | 75.75 g | 25 mm | 44.8 Pa | 0.18 in H2O | 41 CFM | 1.15 m³/min | 3200 RPM | 2 Wire Leads | Vapo-Bearing™ | 1.56 W |
