TEHCBS Series
Manufacturer: Essentra Components
Beta
⌘K
BRD SPT EDGE HOLD SCREW MNT 1"
| Part | Material | Length - Overall [x] | Length - Overall [x] | Mounting Type | Support Panel Thickness | Support Panel Thickness | Support Panel Thickness | Mounting Hole Diameter | Mounting Hole Diameter | Holding Type | Between Board Height | Between Board Height | Support Hole Diameter [diameter] | Support Hole Diameter [diameter] | Between Board Height | Length - Overall | Length - Overall |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Essentra Components | Nylon | 1.598 in | 40.6 mm | Screw Mount | 1.57 mm | 0.062 in | 0.0625 in | 0.118 in | 3 mm | Edge Holding | 25.4 mm | 1 in | 3.99 mm | 0.157 " | |||
 Essentra Components | Nylon | 0.921 in | 23.4 mm | Screw Mount | 1.57 mm | 0.062 in | 0.0625 in | 0.118 in | 3 mm | Edge Holding | 15.88 mm | 0.625 in | 3.99 mm | 0.157 " | 5 8 | ||
Essentra Components | Nylon | Screw Mount | 1.57 mm | 0.062 in | 0.0625 in | 0.118 in | 3 mm | Edge Holding | 9.53 mm | 0.375 in | 3.99 mm | 0.157 " | 0.375 " | 24.7 mm | 0.972 in |
