887-048 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 48POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Termination | Read Out | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Number of Rows [custom] | Features | Card Type | Color | Gender | Mounting Type | Number of Positions/Bay/Row | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Contact Finish | Number of Positions | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Dual | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 2 | Card Extender | Non Specified - Dual Edge | Black | Female | Board Edge Straddle Mount | 24 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 48 | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Dual | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 2 | Card Extender | Non Specified - Dual Edge | Black | Female | Board Edge Straddle Mount | 24 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 48 | 125 °C | -40 C | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Wire Wrap | Dual | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 2 | Non Specified - Dual Edge | Black | Female | Through Hole | 24 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 48 | 125 °C | -40 C | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Dual | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 2 | Non Specified - Dual Edge | Black | Female | Through Hole | 24 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 48 | 125 °C | -40 C | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Dual | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 2 | Non Specified - Dual Edge | Black | Female | Through Hole | 24 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 48 | 125 °C | -40 C | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Dual | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 2 | Card Extender | Non Specified - Dual Edge | Black | Female | Board Edge Straddle Mount | 24 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 48 | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Dual | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 2 | Non Specified - Dual Edge | Black | Female | Right Angle Through Hole | 24 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 48 | 125 °C | -40 C | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Wire Wrap | Dual | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 2 | Non Specified - Dual Edge | Black | Female | Through Hole | 24 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 48 | 125 °C | -40 C | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Dual | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 2 | Non Specified - Dual Edge | Black | Female | Right Angle Through Hole | 24 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 48 | 125 °C | -40 C | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Wire Wrap | Dual | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 2 | Non Specified - Dual Edge | Black | Female | Through Hole | 24 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | 48 | 125 °C | -40 C |
