77127 Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CABLE 3COND 18AWG SHLD
| Part | Shield Coverage | Shield Material | Wire Gauge | Ratings | Operating Temperature [Min] | Operating Temperature [Max] | Voltage | Shield Type | Conductor Strand [custom] | Conductor Strand [custom] | Conductor Material | Cable Type | Features | Length | Length | Jacket (Insulation) Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket Color | Conductor Insulation | Number of Conductors | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | 100 % | Aluminum | 18 AWG | ISO 10993 | -50 °C | 105 ░C | 600 V | Foil | 16 | 30 AWG | Copper Tinned | Multi-Conductor | Biological Compatibility | 304.8 m | 1000 ft | Polyphenylene Ether Modified (mPPE) | 5.51 mm | 0.217 in | Slate | Polyphenylene Ether Modified (mPPE) | 3 | 0.813 mm | 0.032 in | ||
ALPHA WIRE | 100 % | Aluminum | 18 AWG | ISO 10993 | -50 °C | 105 ░C | 600 V | Foil | 16 | 30 AWG | Copper Tinned | Multi-Conductor | Biological Compatibility | Polyphenylene Ether Modified (mPPE) | 5.94 mm | 0.234 in | Slate | Polyphenylene Ether Modified (mPPE) | 4 | 0.813 mm | 0.032 in | ||||
ALPHA WIRE | 100 % | Aluminum | 18 AWG | ISO 10993 | -50 °C | 105 ░C | 600 V | Foil | 16 | 30 AWG | Copper Tinned | Multi-Conductor | Biological Compatibility | Polyphenylene Ether Modified (mPPE) | 5.94 mm | 0.234 in | Slate | Polyphenylene Ether Modified (mPPE) | 4 | 0.813 mm | 0.032 in | 100 ft | 30.5 m |
