333-062 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 62POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Contact Type | Number of Rows [custom] | Contact Material | Contact Finish | Gender | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row [custom] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Card Type | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Color | Number of Positions | Pitch | Pitch | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Cantilever | 2 | Copper Alloy | Gold | Female | 0.25 Ám | 10 Áin | 31 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Wire Wrap | Non Specified - Dual Edge | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Dual | Green | 62 | 3.96 mm | 0.156 in | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Cantilever | 2 | Copper Alloy | Gold | Female | 0.25 Ám | 10 Áin | 31 | 3.25 mm | 0.128 " | Wire Wrap | Non Specified - Dual Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Dual | Green | 62 | 3.96 mm | 0.156 in | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Cantilever | 2 | Copper Alloy | Gold | Female | 0.25 Ám | 10 Áin | 31 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Solder | Non Specified - Dual Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Dual | Green | 62 | 3.96 mm | 0.156 in | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Cantilever | 2 | Copper Alloy | Gold | Female | 0.25 Ám | 10 Áin | 31 | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Solder | Non Specified - Dual Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Dual | Green | 62 | 3.96 mm | 0.156 in | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Cantilever | 2 | Copper Alloy | Gold | Female | 0.25 Ám | 10 Áin | 31 | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | Solder | Non Specified - Dual Edge | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Dual | Green | 62 | 3.96 mm | 0.156 in | Card Extender |
 EDAC Inc. | 2 | Polyester Thermoplastic | Cantilever | 2 | Copper Alloy | Gold | Female | 0.25 Ám | 10 Áin | 31 | 3.25 mm | 0.128 " | Solder | Non Specified - Dual Edge | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Dual | Green | 62 | 3.96 mm | 0.156 in | Card Extender | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Cantilever | 2 | Copper Alloy | Gold | Female | 0.25 Ám | 10 Áin | 31 | Wire Wrap | Non Specified - Dual Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Dual | Green | 62 | 3.96 mm | 0.156 in | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Cantilever | 2 | Copper Alloy | Gold | Female | 0.25 Ám | 10 Áin | 31 | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Solder | Non Specified - Dual Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Dual | Green | 62 | 3.96 mm | 0.156 in | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Cantilever | 2 | Copper Alloy | Gold | Female | 0.25 Ám | 10 Áin | 31 | M3 Threaded Insert Top Mount Opening | Solder | Non Specified - Dual Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Dual | Green | 62 | 3.96 mm | 0.156 in | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Cantilever | 2 | Copper Alloy | Gold | Female | 0.25 Ám | 10 Áin | 31 | M3 Threaded Insert Top Mount Opening | Solder | Non Specified - Dual Edge | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Dual | Green | 62 | 3.96 mm | 0.156 in | Card Extender |
