177-037 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB RCPT 37POS R/A SLDR
| Part | Contact Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Material Flammability Rating | Shell Material, Finish | Shell Size, Connector Layout | Shell Size, Connector Layout | Number of Rows [custom] | Current Rating (Amps) | Termination | Connector Style | Contact Finish | Features | Backset Spacing | Backset Spacing | Mounting Type | Contact Finish Thickness | Number of Positions | Connector Type | Flange Feature | Flange Feature | Contact Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Phosphor Bronze | Black | -55 C | 105 ░C | Polyester Glass Filled | UL94 V-0 | Metal Tin Plated | 4 | DC C | 2 | 5 A | Solder | D-Sub | Gold | Ground Strap | 0.59 in | 14.99 mm | Panel Mount Right Angle Through Hole | Flash | 37 | Receptacle Female Sockets | Housing/Shell | 4-40 | Signal |
 NorComp Inc. | Phosphor Bronze | Black | -55 C | 105 ░C | Polyester Glass Filled | UL94 V-0 | Metal Tin Plated | 4 | DC C | 2 | 5 A | Solder | D-Sub | Gold | Ground Strap Grounding Indents | 0.59 in | 14.99 mm | Panel Mount Right Angle Through Hole | Flash | 37 | Plug Male Pins | Housing/Shell (Unthreaded) | Signal | |
 NorComp Inc. | Phosphor Bronze | Black | -55 C | 105 ░C | Polyester Glass Filled | UL94 V-0 | Metal Tin Plated | 4 | DC C | 2 | 5 A | Solder | D-Sub | Gold | Board Lock Ground Strap | 0.59 in | 14.99 mm | Panel Mount Right Angle Through Hole | Flash | 37 | Receptacle Female Sockets | Housing/Shell | 4-40 | Signal |
 NorComp Inc. | Phosphor Bronze | Black | -55 C | 105 ░C | Polyester Glass Filled | UL94 V-0 | Metal Tin Plated | 4 | DC C | 2 | 5 A | Solder | D-Sub | Gold | Ground Strap Grounding Indents | 0.59 in | 14.99 mm | Panel Mount Right Angle Through Hole | Flash | 37 | Plug Male Pins | 4-40 Mating Side Female Screwlock | Signal | |
 NorComp Inc. | Phosphor Bronze | Black | -55 C | 105 ░C | Polyester Glass Filled | UL94 V-0 | Metal Tin Plated | 4 | DC C | 2 | 5 A | Solder | D-Sub | Gold | Ground Strap | 0.59 in | 14.99 mm | Panel Mount Right Angle Through Hole | Flash | 37 | Receptacle Female Sockets | 4-40 Mating Side Female Screwlock | Signal | |
NorComp Inc. | Phosphor Bronze | Black | -55 C | 105 ░C | Polyester Glass Filled | UL94 V-0 | Metal Tin Plated | 4 | DC C | 2 | 5 A | Solder | D-Sub | Gold | Board Lock Ground Strap Grounding Indents | 0.59 in | 14.99 mm | Panel Mount Right Angle Through Hole | Flash | 37 | Plug Male Pins | 4-40 Mating Side Female Screwlock | Signal |
