DX07S024 Series
Manufacturer: JAE Electronics
Beta
⌘K
CONN RCP USB3.1 TYPEC 24P SMD RA
| Part | Insulation Color | Shell/Shielding Material | Contact Finish | Mounting Type | Specifications | Mating Cycles | Gender | Termination | Mounting Feature | Features | Connector Type | Voltage - Rated | Current Rating (Amps) | Number of Contacts [custom] | Shielding | Operating Temperature [Max] | Operating Temperature [Min] | Number of Ports |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 JAE Electronics | Black | Stainless Steel | Gold | Surface Mount Right Angle Through Hole | USB 3.2 Gen 2 (USB 3.1 Gen 2 Superspeed + (USB 3.1)) | 10000 | Receptacle | Solder | Horizontal | Pick and Place | USB-C (USB TYPE-C) | 48 VDC | 0.25 A 1.25 A | 24 | Shielded | 80 °C | -30 ░C | 1 |
 JAE Electronics | Black | Stainless Steel | Gold | Surface Mount Right Angle Through Hole | USB 3.2 Gen 2 (USB 3.1 Gen 2 Superspeed + (USB 3.1)) | 10000 | Receptacle | Solder | Horizontal | Board Guide | USB-C (USB TYPE-C) | 48 VDC | 0.25 A 1.25 A | 24 | Shielded | 80 °C | -30 ░C | 1 |
 JAE Electronics | Black | Stainless Steel | Gold | Surface Mount Right Angle Through Hole | USB 3.2 Gen 2 (USB 3.1 Gen 2 Superspeed + (USB 3.1)) | 10000 | Receptacle | Solder | Horizontal | Board Guide | USB-C (USB TYPE-C) | 48 VDC | 5 A | 24 | Shielded | 80 °C | -30 ░C | 1 |
 JAE Electronics | Black | Stainless Steel | Gold | Surface Mount Right Angle Through Hole | USB 3.2 Gen 2 (USB 3.1 Gen 2 Superspeed + (USB 3.1)) | 10000 | Receptacle | Solder | Horizontal | Pick and Place | USB-C (USB TYPE-C) | 48 VDC | 0.25 A 1.25 A | 24 | Shielded | 80 °C | -30 ░C | 1 |
 JAE Electronics | Black | Stainless Steel | Gold | Surface Mount Right Angle Through Hole | USB 4.0 | Receptacle | Solder | Horizontal | USB-C (USB TYPE-C) | 48 VDC | 24 | Shielded | 1 | |||||
 JAE Electronics | Black | Stainless Steel | Gold | Surface Mount Right Angle Through Hole | USB 3.2 Gen 2 (USB 3.1 Gen 2 Superspeed + (USB 3.1)) | 10000 | Receptacle | Solder | Horizontal | Board Lock | USB-C (USB TYPE-C) | 0.25 A 1.25 A | 24 | Shielded | 80 °C | -30 ░C | 1 | |
 JAE Electronics | Black | Surface Mount Through Hole | USB 3.2 Gen 2 (USB 3.1 Gen 2 Superspeed + (USB 3.1)) | 10000 | Receptacle | Solder | Vertical | Board Guide | USB-C (USB TYPE-C) | 48 VDC | 5 A | 24 | Unshielded | 80 °C | -30 ░C | 1 | ||
 JAE Electronics | Black | Stainless Steel | Gold | Surface Mount Right Angle Through Hole | USB 3.2 Gen 2 (USB 3.1 Gen 2 Superspeed + (USB 3.1)) | 10000 | Receptacle | Solder | Horizontal | Board Lock | USB-C (USB TYPE-C) | 48 VDC | 0.25 A 1.25 A | 24 | Shielded | 80 °C | -30 ░C | 1 |
 JAE Electronics | Black | Stainless Steel | Gold | Surface Mount Right Angle Through Hole | USB 3.2 Gen 2 (USB 3.1 Gen 2 Superspeed + (USB 3.1)) | 10000 | Receptacle | Solder | Horizontal | Board Guide | USB-C (USB TYPE-C) | 48 VDC | 0.25 A 1.25 A 5 A | 24 | Shielded | 80 °C | -30 ░C | 1 |
 JAE Electronics | Black | Stainless Steel | Gold | Surface Mount Through Hole | USB 3.2 Gen 2 (USB 3.1 Gen 2 Superspeed + (USB 3.1)) | 10000 | Receptacle | Solder | Vertical | Board Guide | USB-C (USB TYPE-C) | 48 VDC | 5 A | 24 | Unshielded | 80 °C | -30 ░C | 1 |
