AMP MCP 1.5K Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
AMP MCP 1.5K, CONTACT
| Part | Connector Type | Number of Rows | Color | Mounting Type | Contact Termination | Insulation Material | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Contact Type | Fastening Type | Contact Finish | Pin or Socket | Wire Gauge [Min] | Wire Gauge [Max] | Wire Gauge [custom] | Wire Gauge [custom] | Type | Number of Rows [custom] | Row Spacing | Row Spacing | Number of Positions | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | |||||||||||||||||||||||||
 TE Connectivity AMP Connectors | Housing for Female Insert | 1 | Black | Free Hanging (In-Line) | Crimp | Polybutylene Terephthalate (PBT) | 130 °C | -40 C | 4 mm | 0.157 in | Female Socket | Latch Holder | |||||||||||||
 TE Connectivity AMP Connectors | Crimp | Tin | Socket | 17.5 AWG | 20 AWG | ||||||||||||||||||||
 TE Connectivity AMP Connectors | |||||||||||||||||||||||||
 TE Connectivity AMP Connectors | Crimp | Tin | Tab | 17 | 20 AWG | Stamped | |||||||||||||||||||
 TE Connectivity AMP Connectors | Crimp | Tin | Socket | 22 AWG | 24 AWG | Stamped | |||||||||||||||||||
 TE Connectivity AMP Connectors | Crimp | Tin | Socket | 17 | 20 AWG | Stamped | |||||||||||||||||||
 TE Connectivity AMP Connectors | Receptacle | Black | Free Hanging (In-Line) | Crimp | Glass Filled Nylon 6/6 Polyamide (PA66) | 125 °C | -25 °C | 5 mm | 0.197 in | Female Socket | 2 | 6 mm | 0.236 in | 12 | |||||||||||
 TE Connectivity AMP Connectors | Crimp | Gold | Socket | 17 | 20 AWG | 31.5 µin | 0.8 µm | ||||||||||||||||||
 TE Connectivity AMP Connectors | Receptacle | 1 | Natural | Free Hanging (In-Line) | Crimp | Polybutylene Terephthalate (PBT) Glass Filled | 120 °C | -40 C | 4 mm | 0.157 in | Female Socket | Locking Ramp | 9 |
