CM1426 Series
4-, 6- and 8-Channel LCD and Camera Filter Arrays with ESD Protection
Manufacturer: ON Semiconductor
Catalog
4-, 6- and 8-Channel LCD and Camera Filter Arrays with ESD Protection
Key Features
• Four, six, or eight lines of filters
Description
AI
The CM1426 is a family of pi-style EMI filter arrays with ESD protection, which integrates four, six and eight filters (C-R-C) in a Chip Scale Package with 0.50mm pad pitch. The CM1426 has component values of 8.5pF-100 Ohm-8.5pF per channel. The CM1426 has a cut-off frequency of 230MHz and can be used in applications where the data rates are as high as 92Mbps. The parts include avalanche-type ESD diodes on every pin that provide a very high level of protection for sensitive electronic components against possible ESD strikes.
