ECW-F2 Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

CAP FILM 0.039UF 5% 450VDC RAD

Part	Package / Case	Termination	Mounting Type	Dielectric Material	Tolerance	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Capacitance	Applications	Voltage Rating - DC	Lead Spacing	Lead Spacing	Voltage Rating - AC	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Size / Dimension [y]
Panasonic Industrial Automation Sales ECW-F2W393JL	Radial	PC Pins	Through Hole	Metallized Polypropylene (PP)	5 %	-40 °C	105 ░C	0.228 in	12.5 mm	5.8 mm	0.492 in	0.039 µF	High Frequency Switching	450 V	0.394 in	10 mm
Panasonic Industrial Automation Sales ECW-F2W824JA	Radial	PC Pins	Through Hole	Metallized Polypropylene (PP)	5 %	-40 °C	105 ░C	0.323 "	18.1 mm	8.2 mm	0.713 in	0.82 µF	High Frequency Switching	450 V	0.591 in	15 mm	84 V	14.2 mm	0.559 in
Panasonic Industrial Automation Sales ECW-F2W684JA	Radial	PC Pins	Through Hole	Metallized Polypropylene (PP)	5 %	-40 °C	105 ░C	0.295 in	18.1 mm	7.5 mm	0.713 in	680 nF	High Frequency Switching	450 V	0.591 in	15 mm	84 V
Panasonic Industrial Automation Sales ECW-F2W335JA	Radial	PC Pins	Through Hole	Metallized Polypropylene (PP)	5 %	-40 °C	105 ░C	0.461 in	26.3 mm	11.7 mm	1.035 "	3.3 µF	High Frequency Switching	450 V	0.886 in	22.5 mm	84 V		19 mm	0.748 in
Panasonic Industrial Automation Sales ECW-F2W155JA	Radial	PC Pins	Through Hole	Metallized Polypropylene (PP)	5 %	-40 °C	105 ░C	0.421 "	18.8 mm	10.7 mm	0.74 in	1.5 µF	High Frequency Switching	450 V	0.591 in	15 mm	84 V				17.3 mm	0.681 in
Panasonic Industrial Automation Sales ECW-F2W334JAQ	Radial	PC Pins	Through Hole	Metallized Polypropylene (PP)	5 %	-40 °C	105 ░C	0.299 in	13 mm		0.512 in	0.33 µF	High Frequency Switching	450 V	0.394 in	10 mm	84 V		18.2 mm	0.717 in			7.6 mm
Panasonic Industrial Automation Sales ECW-F2W475JA	Radial	PC Pins	Through Hole	Metallized Polypropylene (PP)	5 %	-40 °C	105 ░C	0.543 "	26.3 mm	13.8 mm	1.035 "	4.7 µF	High Frequency Switching	450 V	0.886 in	22.5 mm	84 V				21.1 mm	0.831 "
Panasonic Industrial Automation Sales ECW-F2W105JA	Radial	PC Pins	Through Hole	Metallized Polypropylene (PP)	5 %	-40 °C	105 ░C	0.366 "	18.1 mm	9.3 mm	0.713 in	1 µF	High Frequency Switching	450 V	0.591 in	15 mm	84 V				14.1 mm	0.555 in
Panasonic Industrial Automation Sales ECW-F2W184JAB	Radial	PC Pins	Through Hole	Metallized Polypropylene (PP)	5 %	-40 °C	105 ░C	0.24 "	13 mm	6.1 mm	0.512 in	0.18 µF	High Frequency Switching	450 V	0.295 in	7.5 mm					15.2 mm	0.598 in
Panasonic Industrial Automation Sales ECW-F2W395JA	Radial	PC Pins	Through Hole	Metallized Polypropylene (PP)	5 %	-40 °C	105 ░C	0.496 in	26.3 mm	12.6 mm	1.035 "	3.9 µF	High Frequency Switching	450 V	0.886 in	22.5 mm	84 V		19.9 mm	0.783 in
