396-100 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 100POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Color | Contact Type | Gender | Mounting Type | Termination | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Number of Rows [custom] | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Card Type | Read Out | Number of Positions/Bay/Row | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | Cantilever | Female | Through Hole | Wire Wrap | Copper Alloy | -40 C | 105 ░C | 100 | 2 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 50 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 3.18 mm | 0.125 in | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | Cantilever | Female | Right Angle Through Hole | Solder Wire Wrap | Copper Alloy | -40 C | 105 ░C | 100 | 2 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 50 | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 3.18 mm | 0.125 in | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | Cantilever | Female | Board Edge Straddle Mount | Solder Eyelet(s) | Copper Alloy | -40 C | 105 ░C | 100 | 2 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 50 | 4-40 Threaded Insert Top Mount Opening | 3.18 mm | 0.125 in | Card Extender Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | Cantilever | Female | Right Angle Through Hole | Solder Wire Wrap | Copper Alloy | -40 C | 105 ░C | 100 | 2 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 50 | 4-40 Threaded Insert Top Mount Opening | 3.18 mm | 0.125 in | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | Cantilever | Female | Board Edge Straddle Mount | Solder Eyelet(s) | Copper Alloy | -40 C | 105 ░C | 100 | 2 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 50 | 4-40 Threaded Insert Top Mount Opening | 3.18 mm | 0.125 in | Card Extender | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | Cantilever | Female | Through Hole | Solder | Copper Alloy | -40 C | 105 ░C | 100 | 2 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 50 | Flush Mount M3 Threaded Insert Top Opening | 3.18 mm | 0.125 in | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | Cantilever | Female | Through Hole | Wire Wrap | Copper Alloy | -40 C | 105 ░C | 100 | 2 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 50 | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | 3.18 mm | 0.125 in | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | Cantilever | Female | Through Hole | Wire Wrap | Copper Alloy | -40 C | 105 ░C | 100 | 2 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 50 | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " | 3.18 mm | 0.125 in | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | Cantilever | Female | Through Hole | Solder | Copper Alloy | -40 C | 105 ░C | 100 | 2 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 50 | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | 3.18 mm | 0.125 in | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | Cantilever | Female | Right Angle Through Hole | Solder Wire Wrap | Copper Alloy | -40 C | 105 ░C | 100 | 2 | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Dual | 50 | 4-40 Threaded Insert Top Mount Opening | 3.18 mm | 0.125 in | Card Guides |
