PKM711 Series

Catalog

DC DC CONVERTER 5V 100W

Part	Supplier Device Package	Power (Watts)	Operating Temperature [Min]	Operating Temperature [Max]	Efficiency	Control Features	Features	Applications	Standard Number	Number of Outputs	Voltage - Input (Min) [Min]	Package / Case	Voltage - Output 1	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Current - Output (Max) [Max]	Voltage - Input (Max) [Max]	Mounting Type	Type	Voltage - Isolation	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]
Flex Power Modules PKM7111APIPLHS	Quarter Brick	100 W	-40 °C	115 °C	87 %	Active High Enable	Adjustable Output Heat Sink Remote On/Off Remote Sense	ITE (Commercial) Railway	50155 62368-1	1	66 V	Quarter Brick	5 V	2.28 "	1.45 in	25.6 mm	1.01 "	57.9 mm	36.8 mm	20 A	160 V	Through Hole	Isolated Module	3000 V
Flex Power Modules PKM7111APIPHS	Quarter Brick	100 W	-40 °C	115 °C	87 %	Active High Enable	Adjustable Output Heat Sink Remote On/Off Remote Sense	ITE (Commercial) Railway	50155 62368-1	1	66 V	Quarter Brick	5 V			1.29 in		2.28 in	1.45 in	20 A	160 V	Through Hole	Isolated Module	3000 V	36.8 mm	32.7 mm	57.9 mm
Flex Power Modules PKM7115APIPHS	Quarter Brick	100 W	-40 °C	115 °C	90 %	Active High Enable	Adjustable Output Heat Sink Remote On/Off Remote Sense	ITE (Commercial) Railway	50155 62368-1	1	66 V	Quarter Brick	15 V			1.29 in		2.28 in	1.45 in	6.67 A	160 V	Through Hole	Isolated Module	3000 V	36.8 mm	32.7 mm	57.9 mm
Flex Power Modules PKM7113APIPHS	Quarter Brick	100 W	-40 °C	115 °C	90 %	Active High Enable	Adjustable Output Heat Sink Remote On/Off Remote Sense	ITE (Commercial) Railway	50155 62368-1	1	66 V	Quarter Brick	12 V			1.29 in		2.28 in	1.45 in	8.3 A	160 V	Through Hole	Isolated Module	3000 V	36.8 mm	32.7 mm	57.9 mm
Flex Power Modules PKM7113APIPLHS	Quarter Brick	100 W	-40 °C	115 °C	90 %	Active High Enable	Adjustable Output Heat Sink Remote On/Off Remote Sense	ITE (Commercial) Railway	50155 62368-1	1	66 V	Quarter Brick	12 V	2.28 "	1.45 in	25.6 mm	1.01 "	57.9 mm	36.8 mm	8.3 A	160 V	Through Hole	Isolated Module	3000 V
Flex Power Modules PKM7115APIPLHS	Quarter Brick	100 W	-40 °C	115 °C	90 %	Active High Enable	Adjustable Output Heat Sink Remote On/Off Remote Sense	ITE (Commercial) Railway	50155 62368-1	1	66 V	Quarter Brick	15 V	2.28 "	1.45 in	25.6 mm	1.01 "	57.9 mm	36.8 mm	6.67 A	160 V	Through Hole	Isolated Module	3000 V
Flex Power Modules PKM7116JAPIPHS	Quarter Brick	100 W	-40 °C	115 °C	90 %	Active High Enable	Adjustable Output Heat Sink Remote On/Off Remote Sense	ITE (Commercial) Railway	50155 62368-1	1	66 V	Quarter Brick	48 V			1.29 in		2.28 in	1.45 in	2.08 A	160 V	Through Hole	Isolated Module	3000 V	36.8 mm	32.7 mm	57.9 mm
Flex Power Modules PKM7116JAPIP	Quarter Brick	100 W	-40 °C	115 °C	90 %	Active High Enable	Adjustable Output Remote On/Off Remote Sense	ITE (Commercial) Railway	50155 62368-1	1	66 V	Quarter Brick	48 V	2.28 "	1.45 in		0.5 in	57.9 mm		2.08 A	160 V	Through Hole	Isolated Module	3000 V	36.8 mm			12.7 mm
Flex Power Modules PKM7116ZAPIPLHS	Quarter Brick	100 W	-40 °C	115 °C	89 %	Active High Enable	Adjustable Output Heat Sink Remote On/Off Remote Sense	ITE (Commercial) Railway	50155 62368-1	1	66 V	Quarter Brick	24 V	2.28 "	1.45 in	25.6 mm	1.01 "	57.9 mm	36.8 mm	4.16 A	160 V	Through Hole	Isolated Module	3000 V
Flex Power Modules PKM7113APIP	Quarter Brick	100 W	-40 °C	115 °C	90 %	Active High Enable	Adjustable Output Remote On/Off Remote Sense	ITE (Commercial) Railway	50155 62368-1	1	66 V	Quarter Brick	12 V	2.28 "	1.45 in		0.5 in	57.9 mm		8.3 A	160 V	Through Hole	Isolated Module	3000 V	36.8 mm			12.7 mm
