846-094 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 94POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Contact Type | Number of Positions | Termination | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Gender | Color | Card Type | Read Out | Contact Material | Number of Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Features | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | 3.18 mm | 0.125 in | 47 | 0.25 Ám | 10 Áin | Gold | Cantilever | 94 | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Green | Non Specified - Dual Edge | Dual | Copper Alloy | 2 | 125 °C | -40 C | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2.95 mm | 0.116 " | 3.18 mm | 0.125 in | 47 | 0.25 Ám | 10 Áin | Gold | Cantilever | 94 | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Female | Green | Non Specified - Dual Edge | Dual | Copper Alloy | 2 | 125 °C | -40 C | Card Extender | Floating Bobbin Flush Mount |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2.95 mm | 0.116 " | 3.18 mm | 0.125 in | 47 | 0.25 Ám | 10 Áin | Gold | Cantilever | 94 | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Green | Non Specified - Dual Edge | Dual | Copper Alloy | 2 | 125 °C | -40 C | Floating Bobbin Flush Mount | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | 3.18 mm | 0.125 in | 47 | 0.25 Ám | 10 Áin | Gold | Cantilever | 94 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Female | Green | Non Specified - Dual Edge | Dual | Copper Alloy | 2 | 125 °C | -40 C | Card Extender | Flush Mount Side Opening Unthreaded |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | 3.18 mm | 0.125 in | 47 | 0.25 Ám | 10 Áin | Gold | Cantilever | 94 | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Female | Green | Non Specified - Dual Edge | Dual | Copper Alloy | 2 | 125 °C | -40 C | Card Extender | Flush Mount Top Opening Unthreaded |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | 47 | 0.25 Ám | 10 Áin | Gold | Cantilever | 94 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Green | Non Specified - Dual Edge | Dual | Copper Alloy | 2 | 125 °C | -40 C | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | 47 | 0.25 Ám | 10 Áin | Gold | Cantilever | 94 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Green | Non Specified - Dual Edge | Dual | Copper Alloy | 2 | 125 °C | -40 C | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | 3.18 mm | 0.125 in | 47 | 0.25 Ám | 10 Áin | Gold | Cantilever | 94 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Green | Non Specified - Dual Edge | Dual | Copper Alloy | 2 | 125 °C | -40 C | Side Mount Opening Unthreaded | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.25 mm | 0.128 " | 3.18 mm | 0.125 in | 47 | 0.25 Ám | 10 Áin | Gold | Cantilever | 94 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Female | Green | Non Specified - Dual Edge | Dual | Copper Alloy | 2 | 125 °C | -40 C | Side Mount Opening Unthreaded | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 " | 3.18 mm | 0.125 in | 47 | 0.25 Ám | 10 Áin | Gold | Cantilever | 94 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Green | Non Specified - Dual Edge | Dual | Copper Alloy | 2 | 125 °C | -40 C | Flush Mount Top Opening Unthreaded |
