146290 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER VERT 40POS 2.54MM
| Part | Number of Positions Loaded | Insulation Material | Contact Type | Connector Type | Current Rating (Amps) | Overall Contact Length | Overall Contact Length | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Fastening Type | Contact Shape | Number of Rows | Contact Length - Mating [x] | Contact Length - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Shrouding | Pitch - Mating | Pitch - Mating | Contact Length - Post [x] | Contact Length - Post [x] | Mounting Type | Insulation Height | Insulation Height | Contact Material | Number of Positions | Termination | Contact Finish - Post | Insulation Color | Material Flammability Rating | Style | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Finish - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | All | Liquid Crystal Polymer (LCP) | Male Pin | Breakaway Header | 3 A | 0.44 in | 11.18 mm | 2.54 µm | 100 µin | Push-Pull | Square | 1 | 0.23 in | 5.84 mm | -65 ░C | 105 ░C | Unshrouded | 0.1 in | 2.54 mm | 0.12 in | 3.05 mm | Through Hole | 0.09 in | 2.29 mm | Copper Alloy | 40 | Press-Fit Solder | Tin | Black | UL94 V-0 | Board to Board Cable | 2.54 çm | 100 çin | |
TE Connectivity Raychem Cable Protection | All | Liquid Crystal Polymer (LCP) | Male Pin | Breakaway Header | 3 A | 0.44 in | 11.18 mm | 2.54 µm | 100 µin | Push-Pull | Square | 1 | 0.23 in | 5.84 mm | -65 ░C | 105 ░C | Unshrouded | 0.1 in | 2.54 mm | 0.12 in | 3.05 mm | Through Hole | 0.09 in | 2.29 mm | Copper Alloy | Press-Fit Solder | Tin-Lead | Black | UL94 V-0 | Board to Board Cable | 2.54 çm | 100 çin | Tin-Lead | |
 TE Connectivity Raychem Cable Protection | All | Liquid Crystal Polymer (LCP) | Male Pin | Breakaway Header | 3 A | 0.44 in | 11.18 mm | 2.54 µm | 100 µin | Push-Pull | Square | 1 | 0.23 in | 5.84 mm | -65 ░C | 105 ░C | Unshrouded | 0.1 in | 2.54 mm | 0.12 in | 3.05 mm | Through Hole | 0.09 in | 2.29 mm | Copper Alloy | 6 | Press-Fit Solder | Tin | Black | UL94 V-0 | Board to Board Cable | 2.54 çm | 100 çin | |
 TE Connectivity Raychem Cable Protection | All | Liquid Crystal Polymer (LCP) | Male Pin | Breakaway Header | 3 A | 0.44 in | 11.18 mm | 2.54 µm | 100 µin | Push-Pull | Square | 1 | 0.23 in | 5.84 mm | -65 ░C | 105 ░C | Unshrouded | 0.1 in | 2.54 mm | 0.12 in | 3.05 mm | Through Hole | 0.09 in | 2.29 mm | Copper Alloy | 4 | Press-Fit Solder | Tin | Black | UL94 V-0 | Board to Board Cable | 2.54 çm | 100 çin |
