M2113LC Series
Manufacturer: NKK Switches
Beta
⌘K
SWITCH TOGGLE SPDT 0.4VA 28V
| Part | Electrical Life | Circuit | Mounting Type | Panel Cutout Dimensions [diameter] | Illumination Type, Color | Switch Function | Voltage Rating - AC | Features | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating - DC | Bushing Thread | Illumination | Actuator Length [x] | Current Rating (Amps) | Actuator Type | Illumination Voltage (Nominal) | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NKK Switches | 25000 Steps | SPDT | Panel Mount | 6.5 mm | Green/Red LED | On-Off-On | 28 V | Epoxy Sealed Terminals | 55 °C | -10 °C | 28 V | 1/4-40 | Illuminated | 14.7 mm | 0.4 VA | Standard Round | 1.7 VDC 2 VDC | PC Pin |
 NKK Switches | 25000 Steps | SPDT | Panel Mount | 6.5 mm | Green/Red LED | On-Off-On | 125 V | Epoxy Sealed Terminals | 55 °C | -10 °C | 30 V | 1/4-40 | Illuminated | 14.7 mm | 3 A 6 A | Standard Round | 1.7 VDC 2 VDC | Solder Lug |
 NKK Switches | 25000 Steps | SPDT | Panel Mount | 6.5 mm | LED Red | On-Off-On | 28 V | Epoxy Sealed Terminals | 55 °C | -10 °C | 28 V | 1/4-40 | Illuminated | 14.7 mm | 0.4 VA | Standard Round | 2.2 VDC | PC Pin |
