837-009 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 9POS 0.156
| Part | Material - Insulation | Termination Rows | Card Type | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Flange Feature | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Color | Gender | Read Out | Mounting Type | Contact Material | Number of Rows | Pitch | Pitch | Termination | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Gold | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Green | Female | Single | Through Hole | Copper Alloy | 1 | 3.96 mm | 0.156 in | Solder | 9 | 125 °C | -40 C | Cantilever | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Gold | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Green | Female | Single | Right Angle Through Hole | Copper Alloy | 1 | 3.96 mm | 0.156 in | Solder | 9 | 125 °C | -40 C | Cantilever | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Gold | M3 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Green | Female | Single | Through Hole | Copper Alloy | 1 | 3.96 mm | 0.156 in | Wire Wrap | 9 | 125 °C | -40 C | Cantilever | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Gold | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Green | Female | Single | Through Hole | Copper Alloy | 1 | 3.96 mm | 0.156 in | Solder | 9 | 125 °C | -40 C | Cantilever | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Gold | Flush Mount Top Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Green | Female | Single | Through Hole | Copper Alloy | 1 | 3.96 mm | 0.156 in | Solder | 9 | 125 °C | -40 C | Cantilever | 0.156 " | 3.96 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Gold | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Green | Female | Single | Through Hole | Copper Alloy | 1 | 3.96 mm | 0.156 in | Solder Eyelet(s) | 9 | 125 °C | -40 C | Cantilever | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Gold | Side Mount Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Green | Female | Single | Right Angle Through Hole | Copper Alloy | 1 | 3.96 mm | 0.156 in | Solder | 9 | 125 °C | -40 C | Cantilever | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Gold | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Green | Female | Single | Through Hole | Copper Alloy | 1 | 3.96 mm | 0.156 in | Wire Wrap | 9 | 125 °C | -40 C | Cantilever | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Gold | Floating Bobbin Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Green | Female | Single | Through Hole | Copper Alloy | 1 | 3.96 mm | 0.156 in | Solder | 9 | 125 °C | -40 C | Cantilever | 0.116 " | 2.95 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Gold | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 9 | Green | Female | Single | Right Angle Through Hole | Copper Alloy | 1 | 3.96 mm | 0.156 in | Solder | 9 | 125 °C | -40 C | Cantilever |
