1738C Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CABLE 4CON 22AWG SLATE SHLD 500'
| Part | Shield Material | Shield Coverage | Jacket (Insulation) Material | Length | Length | Wire Gauge | Cable Type | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Number of Conductors | Jacket Color | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Conductor Insulation | Conductor Material | Conductor Strand [custom] | Conductor Strand [custom] | Shield Type | Usage | Voltage | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | Copper Bare | 75 % | Poly-Vinyl Chloride (PVC) | 152.4 m | 500 ft | 22 AWG | Multi-Conductor | 0.02 " | 0.508 mm | 80 °C | -20 ░C | 4 | Slate | 0.215 in | 5.46 mm | Poly-Vinyl Chloride (PVC) | Copper Tinned | 30 AWG | 7 | Braid | Communication Control | 300 VDC | ||
 ALPHA WIRE | Copper Bare | 75 % | Poly-Vinyl Chloride (PVC) | 22 AWG | Multi-Conductor | 0.02 " | 0.508 mm | 80 °C | -20 ░C | 4 | Slate | 0.215 in | 5.46 mm | Poly-Vinyl Chloride (PVC) | Copper Tinned | 30 AWG | 7 | Braid | Communication Control | 300 VDC | 100 ft | 30.5 m |
