857-011 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 11POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Rows | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Card Type | Contact Type | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Color | Termination | Number of Positions | Read Out | Contact Material | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 1 | 125 °C | -40 C | Female | Non Specified - Single Edge | Semi Bellows | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 11 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Black | Wire Wrap | 11 | Single | Copper Alloy | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 1 | 125 °C | -40 C | Female | Non Specified - Single Edge | Semi Bellows | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 11 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Black | Solder | 11 | Single | Copper Alloy | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 1 | 125 °C | -40 C | Female | Non Specified - Single Edge | Semi Bellows | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 11 | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Black | Solder | 11 | Single | Copper Alloy | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 1 | 125 °C | -40 C | Female | Non Specified - Single Edge | Semi Bellows | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.96 mm | 0.156 in | 11 | 4-40 Flush Mount Threaded Insert Top Opening | Black | Wire Wrap | 11 | Single | Copper Alloy | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 1 | 125 °C | -40 C | Female | Non Specified - Single Edge | Semi Bellows | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 11 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Black | Solder | 11 | Single | Copper Alloy | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 125 °C | -40 C | Female | Non Specified - Dual Edge | Semi Bellows | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 11 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Black | Solder | 22 | Dual | Copper Alloy | 2 | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 125 °C | -40 C | Female | Non Specified - Dual Edge | Semi Bellows | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 11 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Black | Solder | 22 | Dual | Copper Alloy | 2 | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 1 | 125 °C | -40 C | Female | Non Specified - Single Edge | Semi Bellows | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 11 | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Black | Solder | 11 | Single | Copper Alloy | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 1 | 125 °C | -40 C | Female | Non Specified - Single Edge | Semi Bellows | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 11 | Flush Mount M3 Threaded Insert Top Opening | Black | Solder | 11 | Single | Copper Alloy | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 125 °C | -40 C | Female | Non Specified - Dual Edge | Semi Bellows | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.96 mm | 0.156 in | 11 | Flush Mount M3 Threaded Insert Top Opening | Black | Solder Eyelet(s) | 22 | Dual | Copper Alloy | 2 |
