395-100 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 100POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Color | Contact Material | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Number of Positions | Gender | Number of Positions/Bay/Row | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Pitch | Pitch | Contact Finish | Mounting Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Black | Copper Alloy | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Non Specified - Dual Edge | 100 | Female | 50 | Solder | -40 C | 105 ░C | Dual | 0.25 Ám | 10 Áin | Cantilever | 0.1 " | 2.54 mm | Gold | Through Hole | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Black | Copper Alloy | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | 3.96 mm | Non Specified - Dual Edge | 100 | Female | 50 | Wire Wrap | -40 C | 105 ░C | Dual | 0.25 Ám | 10 Áin | Cantilever | 0.1 " | 2.54 mm | Gold | Through Hole | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Black | Copper Alloy | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 100 | Female | 50 | Wire Wrap | -40 C | 105 ░C | Dual | 0.25 Ám | 10 Áin | Cantilever | 0.1 " | 2.54 mm | Gold | Through Hole | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Black | Copper Alloy | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 100 | Female | 50 | Wire Wrap | -40 C | 105 ░C | Dual | 0.25 Ám | 10 Áin | Cantilever | 0.1 " | 2.54 mm | Gold | Through Hole | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Black | Copper Alloy | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 100 | Female | 50 | Wire Wrap | -40 C | 105 ░C | Dual | 0.25 Ám | 10 Áin | Cantilever | 0.1 " | 2.54 mm | Gold | Through Hole | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Black | Copper Alloy | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | 100 | Female | 50 | Solder Eyelet(s) | -40 C | 105 ░C | Dual | 0.25 Ám | 10 Áin | Cantilever | 0.1 " | 2.54 mm | Gold | Board Edge Straddle Mount | Card Extender Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Black | Copper Alloy | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | 100 | Female | 50 | Solder | -40 C | 105 ░C | Dual | 0.25 Ám | 10 Áin | Cantilever | 0.1 " | 2.54 mm | Gold | Through Hole | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Black | Copper Alloy | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | 100 | Female | 50 | Solder | -40 C | 105 ░C | Dual | 0.25 Ám | 10 Áin | Cantilever | 0.1 " | 2.54 mm | Gold | Through Hole | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Black | Copper Alloy | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | 100 | Female | 50 | Solder | -40 C | 105 ░C | Dual | 0.25 Ám | 10 Áin | Cantilever | 0.1 " | 2.54 mm | Gold | Board Edge Straddle Mount | Card Extender | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Black | Copper Alloy | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | 100 | Female | 50 | Solder Eyelet(s) | -40 C | 105 ░C | Dual | 0.25 Ám | 10 Áin | Cantilever | 0.1 " | 2.54 mm | Gold | Board Edge Straddle Mount | Card Extender |
