EEC-S5 Series

Manufacturer: Panasonic Electronic Components

Catalog

CAP 1F -20% +80% 5.5V T/H

Part	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Termination	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	ESR (Equivalent Series Resistance)	Mounting Type	Voltage - Rated	Size / Dimension [diameter]	Size / Dimension [diameter]	Capacitance	Lead Spacing	Lead Spacing	Lifetime @ Temp.	Tolerance [Max]	Tolerance [Min]	Height - Seated (Max) [Max]	Lead Spacing [x]	Lead Spacing [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]
Panasonic Electronic Components EEC-S5R5V105	Axial Can - Vertical	-25 °C	70 °C	PC Pins	0.827 "	21 mm	30 Ohm	Through Hole	5.5 V	0.748 "	19 mm	1 F	0.197 "	5 mm	1000 Hrs	80 %	-20 %
Panasonic Electronic Components EEC-S5R5H105	Axial Can - Horizontal	-25 °C	70 °C	PC Pins		0.256 in	30 Ohm	Through Hole	5.5 V	0.748 "	19 mm	1 F			1000 Hrs	80 %	-20 %	6.5 mm	0.787 in	20 mm
Panasonic Electronic Components EEC-S5R5V155N	Axial Can - Vertical	-40 C	70 °C	PC Pins	0.827 "	21 mm	30 Ohm	Through Hole	5.5 V			1.5 F	0.197 "	5 mm	1000 Hrs	80 %	-20 %				0.217 in	0.748 in	19 mm	5.5 mm
Panasonic Electronic Components EEC-S5R5H474A	Axial Can - Horizontal	-25 °C	70 °C	PC Pins		0.256 in		Through Hole	5.5 V	0.748 "	19 mm	470 mF			1000 Hrs	200 %	-20 %	6.5 mm	0.787 in	20 mm
Panasonic Electronic Components EEC-S5R5H155A	Axial Can - Horizontal	-25 °C	70 °C	PC Pins		0.256 in		Through Hole	5.5 V	0.748 "	19 mm	1.5 F			1000 Hrs	80 %	-20 %	6.5 mm	0.787 in	20 mm
Panasonic Electronic Components EEC-S5R5H105N	Axial Can - Horizontal	-40 C	70 °C	PC Pins		0.256 in	30 Ohm	Through Hole	5.5 V	0.748 "	19 mm	1 F			1000 Hrs	80 %	-20 %	6.5 mm	0.787 in	20 mm
Panasonic Electronic Components EEC-S5R5H155	Axial Can - Horizontal	-25 °C	70 °C	PC Pins		0.256 in	30 Ohm	Through Hole	5.5 V	0.748 "	19 mm	1.5 F			1000 Hrs	80 %	-20 %	6.5 mm	0.787 in	20 mm
Panasonic Electronic Components EEC-S5R5H105A	Axial Can - Horizontal	-25 °C	70 °C	PC Pins		0.256 in		Through Hole	5.5 V	0.748 "	19 mm	1 F			1000 Hrs	80 %	-20 %	6.5 mm	0.787 in	20 mm
