GEC03S Series

Catalog

CONN HEADER SMD R/A 3POS 2.54MM

Part	Material Flammability Rating	Contact Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Style	Contact Finish - Post	Shrouding	Fastening Type	Contact Material	Contact Shape	Number of Positions Loaded	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Current Rating (Amps)	Contact Length - Mating [x]	Contact Length - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Material	Termination	Connector Type	Insulation Height	Insulation Height	Number of Rows	Pitch - Mating	Pitch - Mating	Insulation Color	Contact Length - Mating [x]
Sullins Connector Solutions GEC03SBSN-M89	UL94 V-0	Male Pin	2.54 çm	100 çin	Board to Board Cable	Tin	Unshrouded	Push-Pull	Phosphor Bronze	Square	All	-65 ░C	150 °C	Surface Mount Right Angle	3 A	0.23 in	5.84 mm	2.54 µm	100 µin	Nylon 9T Polyamide (PA9T)	Solder	Breakaway Header	3.56 mm	0.14 in	1	0.1 in	2.54 mm	Black
Sullins Connector Solutions GEC03SGSN-M89	UL94 V-0	Male Pin	2.54 çm	100 çin	Board to Board Cable	Tin	Unshrouded	Push-Pull	Phosphor Bronze	Square	All	-65 ░C	150 °C	Surface Mount Right Angle	3 A	0.318 "		2.54 µm	100 µin	Nylon 9T Polyamide (PA9T)	Solder	Breakaway Header	3.56 mm	0.14 in	1	0.1 in	2.54 mm	Black	8.08 mm
Sullins Connector Solutions GEC03SABN-M30	UL94 V-0	Male Pin	2.54 çm	100 çin	Board to Board Cable	Tin	Unshrouded	Push-Pull	Phosphor Bronze	Square	All	-65 ░C	150 °C	Surface Mount	3 A	0.23 in	5.84 mm	2.54 µm	100 µin	Nylon 9T Polyamide (PA9T)	Solder	Breakaway Header	2.54 mm	0.1 in	1	0.1 in	2.54 mm	Black
