M80-681 Series

Catalog

HEADER CONNECTOR,PCB MOUNT,PLUG,44 CONTACTS,SKT,0.079 PITCH,SURFACE MOUNT TERMINAL,LOCKING ROHS COMPLIANT: YES

Part	Applications	Contact Shape	Contact Material	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Material	Insulation Height	Insulation Height	Number of Rows [custom]	Insulation Color	Voltage Rating	Connector Type	Mounting Type	Pitch - Mating	Pitch - Mating	Contact Finish - Post	Mated Stacking Heights	Contact Finish - Mating	Number of Positions	Fastening Type	Material Flammability Rating	Contact Type	Termination	Number of Positions Loaded	Operating Temperature [Min]	Operating Temperature [Max]	Row Spacing - Mating	Row Spacing - Mating	Style	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions [custom]	Features
Harwin Inc. M80-6814442	Automotive General Purpose Military	Circular	Beryllium Copper	157.5 Áin	4 Ám	Glass Filled Nylon 4/6 Polyamide (PA46)	5.6 mm	0.22 in	2	Black	120 VDC	Receptacle	Surface Mount	0.079 "	2 mm	Tin	7.85 mm 8.45 mm	Gold	44	Locking Ramp	UL94 V-0	Female Socket	Solder	All	-55 C	125 °C	2 mm	0.079 in	Board to Board Cable	12 Áin	0.3 Ám
Harwin Inc. M80-6813445	Automotive General Purpose Military	Circular	Beryllium Copper	12 µin	0.3 µm	Glass Filled Nylon 4/6 Polyamide (PA46)	5.6 mm	0.22 in	2	Black	120 VDC	Receptacle	Surface Mount	0.079 "	2 mm	Gold	7.85 mm 8.45 mm	Gold		Locking Ramp	UL94 V-0	Female Socket	Solder	All	-55 C	125 °C	2 mm	0.079 in	Board to Board Cable	12 Áin	0.3 Ám	34
Harwin Inc. M80-6812045	Automotive General Purpose Military	Circular	Beryllium Copper	12 µin	0.3 µm	Glass Filled Nylon 4/6 Polyamide (PA46)	5.6 mm	0.22 in	2	Black	120 VDC	Receptacle	Surface Mount	0.079 "	2 mm	Gold	7.85 mm 8.45 mm	Gold	20	Locking Ramp	UL94 V-0	Female Socket	Solder	All	-55 C	125 °C	2 mm	0.079 in	Board to Board Cable	12 Áin	0.3 Ám
Harwin Inc. M80-6811442P	Automotive General Purpose Military	Circular	Beryllium Copper	157.5 Áin	4 Ám	Glass Filled Nylon 4/6 Polyamide (PA46)	5.6 mm	0.22 in	2	Black	120 VDC	Receptacle	Surface Mount	0.079 "	2 mm	Tin	7.85 mm 8.45 mm	Gold	14	Locking Ramp	UL94 V-0	Female Socket	Solder	All	-55 C	125 °C	2 mm	0.079 in	Board to Board Cable	12 Áin	0.3 Ám		Pick and Place
Harwin Inc. M80-6811242P	Automotive General Purpose Military	Circular	Beryllium Copper	157.5 Áin	4 Ám	Glass Filled Nylon 4/6 Polyamide (PA46)	5.6 mm	0.22 in	2	Black	120 VDC	Receptacle	Surface Mount	0.079 "	2 mm	Tin	7.85 mm 8.45 mm	Gold	12	Locking Ramp	UL94 V-0	Female Socket	Solder	All	-55 C	125 °C	2 mm	0.079 in	Board to Board Cable	12 Áin	0.3 Ám		Pick and Place
Harwin Inc. M80-6811842P	Automotive General Purpose Military	Circular	Beryllium Copper	157.5 Áin	4 Ám	Glass Filled Nylon 4/6 Polyamide (PA46)	5.6 mm	0.22 in	2	Black	120 VDC	Receptacle	Surface Mount	0.079 "	2 mm	Tin	7.85 mm 8.45 mm	Gold	18	Locking Ramp	UL94 V-0	Female Socket	Solder	All	-55 C	125 °C	2 mm	0.079 in	Board to Board Cable	12 Áin	0.3 Ám		Pick and Place
Harwin Inc. M80-6812001P	Automotive General Purpose Military	Circular	Beryllium Copper	157.5 Áin	4 Ám	Glass Filled Nylon 4/6 Polyamide (PA46)	5.6 mm	0.22 in	2	Black	120 VDC	Receptacle	Surface Mount	0.079 "	2 mm	Tin-Lead	7.85 mm 8.45 mm	Gold	20	Locking Ramp	UL94 V-0	Female Socket	Solder	All	-55 C	125 °C	2 mm	0.079 in	Board to Board Cable	12 Áin	0.3 Ám		Pick and Place
Harwin Inc. M80-6811642P	Automotive General Purpose Military	Circular	Beryllium Copper	157.5 Áin	4 Ám	Glass Filled Nylon 4/6 Polyamide (PA46)	5.6 mm	0.22 in	2	Black	120 VDC	Receptacle	Surface Mount	0.079 "	2 mm	Tin	7.85 mm 8.45 mm	Gold	16	Locking Ramp	UL94 V-0	Female Socket	Solder	All	-55 C	125 °C	2 mm	0.079 in	Board to Board Cable	12 Áin	0.3 Ám		Pick and Place
Harwin Inc. M80-6811445	Automotive General Purpose Military	Circular	Beryllium Copper	12 µin	0.3 µm	Glass Filled Nylon 4/6 Polyamide (PA46)	5.6 mm	0.22 in	2	Black	120 VDC	Receptacle	Surface Mount	0.079 "	2 mm	Gold	7.85 mm 8.45 mm	Gold	14	Locking Ramp	UL94 V-0	Female Socket	Solder	All	-55 C	125 °C	2 mm	0.079 in	Board to Board Cable	12 Áin	0.3 Ám
Harwin Inc. M80-6810442	Automotive General Purpose Military	Circular	Beryllium Copper	157.5 Áin	4 Ám	Glass Filled Nylon 4/6 Polyamide (PA46)	5.6 mm	0.22 in	2	Black	120 VDC	Receptacle	Surface Mount	0.079 "	2 mm	Tin	7.85 mm 8.45 mm	Gold	4	Locking Ramp	UL94 V-0	Female Socket	Solder	All	-55 C	125 °C	2 mm	0.079 in	Board to Board Cable	12 Áin	0.3 Ám
