807-027 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 54POS 0.156
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Color | Number of Positions | Card Type | Read Out | Contact Finish | Mounting Type | Material - Insulation | Termination | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Number of Positions/Bay/Row | Number of Rows [custom] | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Gender | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 125 °C | -40 C | Semi Bellows | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Green | 54 | Non Specified - Dual Edge | Dual | Gold | Through Hole | Diallyl Phthalate (DAP) | Wire Wrap | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 27 | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 1 | |
 EDAC Inc. | 125 °C | -40 C | Semi Bellows | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Green | 27 | Non Specified - Single Edge | Single | Gold | Through Hole | Diallyl Phthalate (DAP) | Solder | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 27 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 1 | 1 | |
 EDAC Inc. | 125 °C | -40 C | Semi Bellows | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Green | 54 | Non Specified - Dual Edge | Dual | Tin | Through Hole | Diallyl Phthalate (DAP) | Solder Eyelet(s) | 3.96 mm | 0.156 in | 27 | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 1 | |||
 EDAC Inc. | 125 °C | -40 C | Semi Bellows | Flush Mount M3 Threaded Insert Top Opening | Green | 27 | Non Specified - Single Edge | Single | Tin | Right Angle Through Hole | Diallyl Phthalate (DAP) | Solder | 3.96 mm | 0.156 in | 27 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 1 | 1 | |||||
 EDAC Inc. | 125 °C | -40 C | Semi Bellows | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Green | 54 | Non Specified - Dual Edge | Dual | Tin | Right Angle Through Hole | Diallyl Phthalate (DAP) | Solder | 3.96 mm | 0.156 in | 27 | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 1 | |||
 EDAC Inc. | 125 °C | -40 C | Semi Bellows | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Green | 27 | Non Specified - Single Edge | Single | Gold | Through Hole | Diallyl Phthalate (DAP) | Wire Wrap | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 27 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 1 | 1 | |
 EDAC Inc. | 125 °C | -40 C | Semi Bellows | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Green | 54 | Non Specified - Dual Edge | Dual | Tin | Right Angle Through Hole | Diallyl Phthalate (DAP) | Solder | 3.96 mm | 0.156 in | 27 | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 1 | |||
 EDAC Inc. | 125 °C | -40 C | Semi Bellows | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Green | 54 | Non Specified - Dual Edge | Dual | Gold | Right Angle Through Hole | Diallyl Phthalate (DAP) | Solder | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 27 | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 1 | |
 EDAC Inc. | 125 °C | -40 C | Semi Bellows | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Green | 54 | Non Specified - Dual Edge | Dual | Tin | Right Angle Through Hole | Diallyl Phthalate (DAP) | Solder | 3.96 mm | 0.156 in | 27 | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 1 | |||
 EDAC Inc. | 125 °C | -40 C | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Green | 54 | Non Specified - Dual Edge | Dual | Tin | Through Hole | Diallyl Phthalate (DAP) | Wire Wrap | 3.96 mm | 0.156 in | 27 | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 1 |
