333-008 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 8POS 0.156
| Part | Material - Insulation | Termination Rows | Contact Type | Contact Material | Pitch | Pitch | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions/Bay/Row | Card Type | Number of Rows | Gender | Termination | Read Out | Flange Feature [diameter] | Flange Feature [diameter] | Color | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Copper Alloy | 3.96 mm | 0.156 in | 8 | -40 C | 105 ░C | 8 | Non Specified - Single Edge | 1 | Female | Wire Wrap | Single | 3.25 mm | 0.128 " | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Copper Alloy | 3.96 mm | 0.156 in | 8 | -40 C | 105 ░C | 8 | Non Specified - Single Edge | 1 | Female | Solder | Single | 3.96 mm | 0.156 " | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Copper Alloy | 3.96 mm | 0.156 in | 8 | -40 C | 105 ░C | 8 | Non Specified - Single Edge | 1 | Female | Solder | Single | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Right Angle Through Hole | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Copper Alloy | 3.96 mm | 0.156 in | 8 | -40 C | 105 ░C | 8 | Non Specified - Single Edge | 1 | Female | Solder | Single | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | 0.25 Ám | 10 Áin | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Copper Alloy | 3.96 mm | 0.156 in | 8 | -40 C | 105 ░C | 8 | Non Specified - Single Edge | 1 | Female | Wire Wrap | Single | 2.95 mm | 0.116 " | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | 0.25 Ám | 10 Áin | Floating Bobbin Flush Mount |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Copper Alloy | 3.96 mm | 0.156 in | 8 | -40 C | 105 ░C | 8 | Non Specified - Single Edge | 1 | Female | Wire Wrap | Single | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Copper Alloy | 3.96 mm | 0.156 in | 8 | -40 C | 105 ░C | 8 | Non Specified - Single Edge | 1 | Female | Wire Wrap | Single | 2.95 mm | 0.116 " | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Copper Alloy | 3.96 mm | 0.156 in | 8 | -40 C | 105 ░C | 8 | Non Specified - Single Edge | 1 | Female | Wire Wrap | Single | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Copper Alloy | 3.96 mm | 0.156 in | 8 | -40 C | 105 ░C | 8 | Non Specified - Single Edge | 1 | Female | Solder | Single | 3.96 mm | 0.156 " | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded |
 EDAC Inc. | Polyester Thermoplastic | 1 | Cantilever | Copper Alloy | 3.96 mm | 0.156 in | 8 | -40 C | 105 ░C | 8 | Non Specified - Single Edge | 1 | Female | Wire Wrap | Single | 3.25 mm | 0.128 " | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Through Hole | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded |
