333-012 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 12POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Number of Rows [custom] | Gender | Contact Material | Card Type | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Pitch | Pitch | Contact Type | Number of Positions/Bay/Row | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Read Out | Color | Termination | Features | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Female | Copper Alloy | Non Specified - Dual Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.96 mm | 0.156 in | Cantilever | 6 | 12 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Dual | Green | Solder | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Female | Copper Alloy | Non Specified - Dual Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | 3.96 mm | 0.156 in | Cantilever | 6 | 12 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 4-40 Threaded Insert Top Mount Opening | Dual | Green | Solder | Card Extender | ||||
 EDAC Inc. | Polyester Thermoplastic | Female | Copper Alloy | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 3.96 mm | 0.156 in | Cantilever | 12 | 12 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Single | Green | Solder | 1 | 1 | ||||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Female | Copper Alloy | Non Specified - Dual Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.96 mm | 0.156 in | Cantilever | 6 | 12 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Dual | Green | Wire Wrap | |||
 EDAC Inc. | Polyester Thermoplastic | Female | Copper Alloy | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 3.96 mm | 0.156 in | Cantilever | 12 | 12 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | M3 Threaded Insert Top Mount Opening | Single | Green | Solder | 1 | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | Female | Copper Alloy | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.96 mm | 0.156 in | Cantilever | 12 | 12 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Single | Green | Wire Wrap | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Female | Copper Alloy | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.96 mm | 0.156 in | Cantilever | 12 | 12 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Single | Green | Solder Eyelet(s) | 1 | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | Female | Copper Alloy | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.96 mm | 0.156 in | Cantilever | 12 | 12 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Single | Green | Solder | 1 | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | Female | Copper Alloy | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.96 mm | 0.156 in | Cantilever | 12 | 12 | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Single | Green | Solder | 1 | 1 | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Female | Copper Alloy | Non Specified - Dual Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.96 mm | 0.156 in | Cantilever | 6 | 12 | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | Dual | Green | Solder |
