PZC29 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN HEADER R/A 29POS 2.54MM

Part	Current Rating (Amps)	Contact Finish - Mating	Contact Shape	Connector Type	Style	Insulation Height	Insulation Height	Pitch - Mating	Pitch - Mating	Shrouding	Termination	Insulation Material	Contact Length - Post	Contact Length - Post	Fastening Type	Number of Positions	Number of Positions Loaded	Contact Material	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Length - Mating	Contact Length - Mating	Insulation Color	Contact Type	Material Flammability Rating	Number of Rows	Mounting Type	Contact Finish - Post	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Number of Rows [custom]	Overall Contact Length	Overall Contact Length	Overall Contact Length [x]	Overall Contact Length [x]
Sullins Connector Solutions PZC29SGAN	3 A	Gold	Square	Header	Board to Board Cable	3.56 mm	0.14 in	0.1 "	2.54 mm	Unshrouded	Solder	Polyester Thermoplastic	3.05 mm	0.12 in	Push-Pull	29	All	Copper Alloy	0.25 µm	10 µin	2.54 µm	100 µin	8.08 mm	0.318 in	Black	Male Pin	UL94 V-0	1	Right Angle Through Hole	Tin
Sullins Connector Solutions PZC29DFDN	3 A	Gold	Square	Header	Board to Board Cable	2.54 mm	0.1 in	0.1 "	2.54 mm	Unshrouded	Solder	Polyester Thermoplastic	10.67 mm	0.42 in	Push-Pull	58	All	Copper Alloy	0.25 µm	10 µin	2.54 µm	100 µin	8.08 mm	0.318 in	Black	Male Pin	UL94 V-0		Through Hole	Tin	0.1 in	2.54 mm	2	21.29 mm	0.838 in
Sullins Connector Solutions PZC29SFAN	3 A	Gold	Square	Header	Board to Board Cable	2.54 mm	0.1 in	0.1 "	2.54 mm	Unshrouded	Solder	Polyester Thermoplastic	3.05 mm	0.12 in	Push-Pull	29	All	Copper Alloy	0.25 µm	10 µin	2.54 µm	100 µin	8.08 mm	0.318 in	Black	Male Pin	UL94 V-0	1	Through Hole	Tin						13.67 mm	0.538 in
Sullins Connector Solutions PZC29DFBN	3 A	Gold	Square	Header	Board to Board Cable	2.54 mm	0.1 in	0.1 "	2.54 mm	Unshrouded	Solder	Polyester Thermoplastic	5.58 mm	0.22 in	Push-Pull	58	All	Copper Alloy	0.25 µm	10 µin	2.54 µm	100 µin	8.08 mm	0.318 in	Black	Male Pin	UL94 V-0		Through Hole	Tin	0.1 in	2.54 mm	2	16.21 mm	0.638 in
Sullins Connector Solutions PZC29DFAN	3 A	Gold	Square	Header	Board to Board Cable	2.54 mm	0.1 in	0.1 "	2.54 mm	Unshrouded	Solder	Polyester Thermoplastic	3.05 mm	0.12 in	Push-Pull	58	All	Copper Alloy	0.25 µm	10 µin	2.54 µm	100 µin	8.08 mm	0.318 in	Black	Male Pin	UL94 V-0		Through Hole	Tin	0.1 in	2.54 mm	2			13.67 mm	0.538 in
Sullins Connector Solutions PZC29SBDN	3 A	Gold	Square	Header	Board to Board Cable	3.56 mm	0.14 in	0.1 "	2.54 mm	Unshrouded	Solder	Polyester Thermoplastic	10.67 mm	0.42 in	Push-Pull	29	All	Copper Alloy	0.25 µm	10 µin	2.54 µm	100 µin	5.84 mm	0.23 in	Black	Male Pin	UL94 V-0	1	Right Angle Through Hole	Tin
Sullins Connector Solutions PZC29DAEN	3 A	Gold	Square	Header	Board to Board Cable	2.54 mm	0.1 in	0.1 "	2.54 mm	Unshrouded	Solder	Polyester Thermoplastic	13.21 mm	0.52 in	Push-Pull	58	All	Copper Alloy	0.25 µm	10 µin	2.54 µm	100 µin	5.84 mm	0.23 in	Black	Male Pin	UL94 V-0		Through Hole	Tin	0.1 in	2.54 mm	2	21.59 mm	0.85 in
Sullins Connector Solutions PZC29SGBN	3 A	Gold	Square	Header	Board to Board Cable	3.56 mm	0.14 in	0.1 "	2.54 mm	Unshrouded	Solder	Polyester Thermoplastic	5.58 mm	0.22 in	Push-Pull	29	All	Copper Alloy	0.25 µm	10 µin	2.54 µm	100 µin	8.08 mm	0.318 in	Black	Male Pin	UL94 V-0	1	Right Angle Through Hole	Tin
Sullins Connector Solutions PZC29SBEN	3 A	Gold	Square	Header	Board to Board Cable	3.56 mm	0.14 in	0.1 "	2.54 mm	Unshrouded	Solder	Polyester Thermoplastic	13.21 mm	0.52 in	Push-Pull	29	All	Copper Alloy	0.25 µm	10 µin	2.54 µm	100 µin	5.84 mm	0.23 in	Black	Male Pin	UL94 V-0	1	Right Angle Through Hole	Tin
Sullins Connector Solutions PZC29SBBN	3 A	Gold	Square	Header	Board to Board Cable	3.56 mm	0.14 in	0.1 "	2.54 mm	Unshrouded	Solder	Polyester Thermoplastic	5.84 mm	0.23 "	Push-Pull	29	All	Copper Alloy	0.25 µm	10 µin	2.54 µm	100 µin	5.84 mm	0.23 in	Black	Male Pin	UL94 V-0	1	Right Angle Through Hole	Tin
