717-007 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 7POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Color | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Termination | Read Out | Pitch | Pitch | Contact Finish | Card Type | Number of Rows | Contact Type | Gender | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 7 | -40 C | 105 ░C | 7 | Black | 30 Áin | 0.76 Ám | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Press-Fit Wire Wrap | Single | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | 1 | Cantilever | Female | Through Hole |
 EDAC Inc. | Polyester Thermoplastic | 1 | 7 | -40 C | 105 ░C | 7 | Black | 30 Áin | 0.76 Ám | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Press-Fit | Single | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | 1 | Cantilever | Female | Through Hole |
 EDAC Inc. | Polyester Thermoplastic | 1 | 7 | -40 C | 105 ░C | 7 | Black | 30 Áin | 0.76 Ám | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Press-Fit Wire Wrap | Single | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | 1 | Cantilever | Female | Through Hole |
 EDAC Inc. | Polyester Thermoplastic | 1 | 7 | -40 C | 105 ░C | 7 | Black | 30 Áin | 0.76 Ám | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Press-Fit | Single | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | 1 | Cantilever | Female | Through Hole |
 EDAC Inc. | Polyester Thermoplastic | 1 | 7 | -40 C | 105 ░C | 7 | Black | 30 Áin | 0.76 Ám | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Press-Fit | Single | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | 1 | Cantilever | Female | Through Hole |
