82641 Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 2COND 24AWG NATURAL
| Part | Shield Coverage | Shield Material | Conductor Material | Number of Conductors | Usage | Features | Length | Length | Conductor Strand [custom] | Conductor Strand [custom] | Cable Type | Conductor Insulation | Wire Gauge | Jacket (Insulation) Diameter | Jacket (Insulation) Diameter | Voltage | Jacket (Insulation) Material | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Shield Type | Operating Temperature [Min] | Operating Temperature [Max] | Jacket Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 100 % | Aluminum | Copper Tinned | 2 | Audio Control Instrumentation | Drain Wire | 304.8 m | 1000 ft | 7 | 32 AWG | Multi-Conductor | Fluorinated Ethylene-Propylene (FEP) | 24 AWG | 0.106 in | 2.69 mm | 300 VDC | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | 0.014 in | 0.356 mm | Foil | 0 °C | 60 °C | Natural |
