HTB18L Series

Catalog

LASER SENSOR, 300MM, PNP, 30VDC ROHS COMPLIANT: YES

Part	Light Source	Ingress Protection	Response Time	Operating Temperature [Max]	Operating Temperature [Min]	Adjustment Type	Output Configuration	Sensing Method	Voltage - Supply [Min]	Voltage - Supply [Max]	Connection Method	Sensing Distance [Max]	Sensing Distance [Min]	Sensing Distance [Max]	Sensing Distance [Min]	Cable Length	Cable Length
SICK, Inc. HTB18L-P1G5BB	Red Laser Diode (655nm)	IP67	500 µs	55 °C	-30 °C	Adjustable Potentiometer	PNP	Proximity	10 VDC	30 VDC	Cable	300 mm	30 mm	11.811 "	1.181 in	78.74 "	2 m
SICK, Inc. 1085700	Red Laser Diode (655nm)	IP67	500 µs	55 °C	-30 °C	Adjustable Potentiometer	NPN	Proximity	10 VDC	30 VDC	Connector M12	300 mm	30 mm	11.811 "	1.181 in
SICK, Inc. 1085418	Red LED	IP67	500 µs	55 °C	-30 °C	Adjustable Potentiometer	NPN	Proximity	10 VDC	30 VDC	Connector M12	300 mm	30 mm	11.811 "	1.181 in
SICK, Inc. 1078770	Red Laser Diode (655nm)	IP67	500 µs	55 °C	-30 °C	Adjustable Potentiometer	NPN PNP	Proximity	10 VDC	30 VDC	Connector M12	300 mm	30 mm	11.811 "	1.181 in
SICK, Inc. 1085701	Red LED	IP67	500 µs	55 °C	-30 °C	Adjustable Potentiometer	NPN	Proximity	10 VDC	30 VDC	Connector M12	300 mm	30 mm	11.811 "	1.181 in
SICK, Inc. 1071033	Red Laser Diode (655nm)	IP67		55 °C	-30 °C	Adjustable Potentiometer	NPN	Proximity	10 VDC	30 VDC	Connector M8	300 mm	30 mm	11.811 "	1.181 in
SICK, Inc. 1078820	Red Laser Diode (655nm)	IP67	500 µs	55 °C	-30 °C	Adjustable Potentiometer	PNP	Proximity	10 VDC	30 VDC	Connector M12	300 mm	30 mm	11.811 "	1.181 in
SICK, Inc. 1081974	Red LED	IP67	500 µs	55 °C	-30 °C	Adjustable Potentiometer	NPN PNP	Proximity	10 VDC	30 VDC	Connector M12	300 mm	30 mm	11.811 "	1.181 in
SICK, Inc. HTB18L-B4B5BH	Red Laser Diode (655nm)	IP67 IP69K	500 µs	55 °C	-30 °C	Adjustable Potentiometer	NPN PNP	Proximity	10 VDC	30 VDC	Cable with Connector	300 mm	30 mm	11.811 "	1.181 in	5.906 in	150 mm
SICK, Inc. 1085523	Red Laser Diode (655nm)	IP67	500 µs	55 °C	-30 °C	Adjustable Potentiometer	PNP	Proximity	10 VDC	30 VDC	Connector M12	300 mm	30 mm	11.811 "	1.181 in
