YC358LJK Series

Manufacturer: YAGEO

Catalog

RES ARRAY 8 RES 30K OHM 2512

Part	Tolerance	Operating Temperature (Max)	Operating Temperature (Min)	Number of Pins	Resistance	Number of Resistors	Mounting Type	Circuit Type	Package / Case	Height - Seated (Max)	Temperature Coefficient	Power Per Element	Size / Dimension Length	Size / Dimension Width	Applications
YAGEO YC358LJK-0730KL	5 %	155 °C	-55 °C	10	30 kOhm	8	Surface Mount	Bussed	2512 (6432 Metric) Convex Long Side Terminals	0.028 in	200 ppm/°C	62.5 mW	0.252 in	0.126 in	DDRAM SDRAM
YAGEO YC358LJK-073KL	5 %	155 °C	-55 °C	10	3 kOhm	8	Surface Mount	Bussed	2512 (6432 Metric) Convex Long Side Terminals	0.028 in	200 ppm/°C	62.5 mW	0.252 in	0.126 in	DDRAM SDRAM
YAGEO YC358LJK-0713KL	5 %	155 °C	-55 °C	10	13 kOhm	8	Surface Mount	Bussed	2512 (6432 Metric) Convex Long Side Terminals	0.028 in	200 ppm/°C	62.5 mW	0.252 in	0.126 in	DDRAM SDRAM
YAGEO YC358LJK-076K8L	5 %	155 °C	-55 °C	10	6.8 kOhm	8	Surface Mount	Bussed	2512 (6432 Metric) Convex Long Side Terminals	0.028 in	200 ppm/°C	62.5 mW	0.252 in	0.126 in	DDRAM SDRAM
YAGEO YC358LJK-075K6L	5 %	155 °C	-55 °C	10	5.6 kOhm	8	Surface Mount	Bussed	2512 (6432 Metric) Convex Long Side Terminals	0.028 in	200 ppm/°C	62.5 mW	0.252 in	0.126 in	DDRAM SDRAM
YAGEO YC358LJK-0727KL	5 %	155 °C	-55 °C	10	27 kOhm	8	Surface Mount	Bussed	2512 (6432 Metric) Convex Long Side Terminals	0.028 in	200 ppm/°C	62.5 mW	0.252 in	0.126 in	DDRAM SDRAM
YAGEO YC358LJK-072KL	5 %	155 °C	-55 °C	10	2 kOhm	8	Surface Mount	Bussed	2512 (6432 Metric) Convex Long Side Terminals	0.028 in	200 ppm/°C	62.5 mW	0.252 in	0.126 in	DDRAM SDRAM
YAGEO YC358LJK-076K2L	5 %	155 °C	-55 °C	10	6.2 kOhm	8	Surface Mount	Bussed	2512 (6432 Metric) Convex Long Side Terminals	0.028 in	200 ppm/°C	62.5 mW	0.252 in	0.126 in	DDRAM SDRAM
YAGEO YC358LJK-0720RL	5 %	155 °C	-55 °C	10	20 Ohm	8	Surface Mount	Bussed	2512 (6432 Metric) Convex Long Side Terminals	0.028 in	200 ppm/°C	62.5 mW	0.252 in	0.126 in	DDRAM SDRAM
YAGEO YC358LJK-07110RL	5 %	155 °C	-55 °C	10	110 Ohm	8	Surface Mount	Bussed	2512 (6432 Metric) Convex Long Side Terminals	0.028 in	200 ppm/°C	62.5 mW	0.252 in	0.126 in	DDRAM SDRAM
