PESD5V0U2BMB Series

Ultra low capacitance bidirectional fivefold ESD protection array

Manufacturer: Freescale Semiconductor - NXP

Catalog

Ultra low capacitance bidirectional fivefold ESD protection array

Part	Power - Peak Pulse	Current - Peak Pulse (10/1000µs)	Voltage - Breakdown (Min) [Min]	Voltage - Clamping (Max) @ Ipp [Max]	Supplier Device Package	Capacitance @ Frequency	Applications	Bidirectional Channels [custom]	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Voltage - Reverse Standoff (Typ)	Type	Package / Case	Package / Case	Voltage - Clamping (Max) @ Ipp	Unidirectional Channels [custom]	Voltage - Reverse Standoff (Typ) [Max]	Bidirectional Channels	Package / Case [custom]	Package / Case	Grade	Qualification
Freescale Semiconductor - NXP PESD5V0S1BSF/S500315	100 W	8 A	10 V	15.5 V	DSN0603-2	35 pF	Telecom	1	-55 °C	150 °C	Surface Mount	5 V	Zener	0603 Metric	0201
Freescale Semiconductor - NXP PESD5V0C1USF/S50YL		9 A	5.5 V		2-DSN0603	0.45 pF	General Purpose		-40 °C	125 °C	Surface Mount	5 V	Zener		2-XFDFN	3 V	1
Freescale Semiconductor - NXP PESD5V2S18U,118	100 W	10 A	6.4 V		20-SSOP	100 pF	General Purpose		-65 °C	150 °C	Surface Mount		Zener		20-SSOP	12 V	18	5.2 V
Freescale Semiconductor - NXP PESD5V0R1BSF/S50YL
Freescale Semiconductor - NXP PESD5V0H1BSF/S50YL
Freescale Semiconductor - NXP PESD5V0L5UK,132
Freescale Semiconductor - NXP PESD5V2S2UT/ZLR
Freescale Semiconductor - NXP PESD5V0U2BMB,315
Freescale Semiconductor - NXP PESD5V0L7BAS,118	35 W	2.5 A	7.2 V	17 V	8-TSSOP	8 pF	General Purpose		-65 °C	150 °C	Surface Mount	5 V	Zener		8-MSOP 8-TSSOP				7	0.118 in	3 mm
Freescale Semiconductor - NXP PESD5V0S1BA/ZLX	130 W	12 A	5.5 V	14 V	SOD-323	35 pF	Telecom	1	-55 °C	150 °C	Surface Mount	5 V	Zener		SC-76 SOD-323							Automotive	AEC-Q101

Catalog

Ultra low capacitance bidirectional fivefold ESD protection array

Description

Ultra low capacitance bidirectional double ElectroStatic Discharge (ESD) protection array designed to protect up to two signal lines from the damage caused by ESD and other transients. The device is housed in a leadless ultra small SOT883B (DFN1006B-3) Surface-Mounted Device (SMD) plastic package.
