CI3104P1 Series
Manufacturer: Cvilux USA
Beta
⌘K
4 POS 2.54MM(.100) WIRE TO BOARD
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Mounting Type | Current Rating (Amps) | Shrouding | Style | Insulation Height | Insulation Height | Pitch - Mating | Pitch - Mating | Contact Material | Material Flammability Rating | Number of Positions Loaded | Overall Contact Length | Overall Contact Length | Contact Shape | Connector Type | Contact Finish - Post | Contact Length - Mating | Contact Length - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Number of Rows | Insulation Material | Operating Temperature [Max] | Operating Temperature [Min] | Fastening Type | Contact Length - Post [x] | Contact Length - Post | Insulation Color | Termination | Number of Positions | Voltage Rating | Contact Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cvilux USA | 120 Áin | 3.05 Ám | Through Hole | 3 A | Shrouded - 1 Wall | Board to Cable/Wire | 11.5 mm | 0.453 in | 0.1 " | 2.54 mm | Brass | UL94 V-0 | All | 14.2 mm | 0.559 " | Square | Header | Tin | 7.49 mm | 0.295 in | 120 µin | 3.05 µm | 1 | Thermoplastic Halogen Free | 85 °C | -25 °C | Friction Lock | 0.134 " | 3.4 mm | Natural | Solder | 4 | 250 VAC | Male Pin |
