EXP-A921 Series

Catalog

CONN CIRCULAR PIN 2 POS SCREW ST CABLE MOUNT 2 TERMINAL 1 PORT

Part	Current Rating (Amps)	Contact Material	Termination	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Backshell Material, Plating	Shell Material	Cable Opening [Min]	Cable Opening [Max]	Cable Opening [Max]	Cable Opening [Min]	Shielding	Connector Type	Mounting Type	Ingress Protection	Features	Number of Positions	Contact Finish - Mating	Orientation	Primary Material	Fastening Type	Color	Material Flammability Rating	Voltage Rating
BULGIN LIMITED EXP-A921/02/P	18 A	Brass	Screw	Industrial	55 °C	-20 ░C	Polyester	Polyester	20 mm	0.866 in	22 mm	0.787 in	Unshielded	Receptacle Male Pins	Free Hanging (In-Line)	IP68 - Dust Tight Waterproof	Backshell Cable Clamp UV Resistant	2	Nickel	Keyed	Plastic	Threaded	Black	UL94 V-0	600 VAC
BULGIN LIMITED EXP-A921/05/S	18 A	Brass	Screw	Industrial	55 °C	-20 ░C	Polyester	Polyester	20 mm	0.866 in	22 mm	0.787 in	Unshielded	Receptacle Female Sockets	Free Hanging (In-Line)	IP68 - Dust Tight Waterproof	Backshell Cable Clamp Trailing Neutral UV Resistant	5	Nickel	Keyed	Plastic	Threaded	Black	UL94 V-0	600 VAC
BULGIN LIMITED EXP-A921/10/P	10 A	Brass	Screw	Industrial	55 °C	-20 ░C	Polyester	Polyester	20 mm	0.866 in	22 mm	0.787 in	Unshielded	Receptacle Male Pins	Free Hanging (In-Line)	IP68 - Dust Tight Waterproof	Backshell Cable Clamp UV Resistant	10	Nickel	Keyed	Plastic	Threaded	Black	UL94 V-0	250 VAC
BULGIN LIMITED EXP-A921/03/S	18 A	Brass	Screw	Industrial	55 °C	-20 ░C	Polyester	Polyester	20 mm	0.866 in	22 mm	0.787 in	Unshielded	Receptacle Female Sockets	Free Hanging (In-Line)	IP68 - Dust Tight Waterproof	Backshell Cable Clamp UV Resistant	3	Nickel	Keyed	Plastic	Threaded	Black	UL94 V-0	600 VAC
BULGIN LIMITED EXP-A921/03/P	18 A	Brass	Screw	Industrial	55 °C	-20 ░C	Polyester	Polyester	20 mm	0.866 in	22 mm	0.787 in	Unshielded	Receptacle Male Pins	Free Hanging (In-Line)	IP68 - Dust Tight Waterproof	Backshell Cable Clamp UV Resistant	3	Nickel	Keyed	Plastic	Threaded	Black	UL94 V-0	600 VAC
BULGIN LIMITED EXP-A921/10/S	10 A	Brass	Screw	Industrial	55 °C	-20 ░C	Polyester	Polyester	20 mm	0.866 in	22 mm	0.787 in	Unshielded	Receptacle Female Sockets	Free Hanging (In-Line)	IP68 - Dust Tight Waterproof	Backshell Cable Clamp UV Resistant	10	Nickel	Keyed	Plastic	Threaded	Black	UL94 V-0	250 VAC
