342-050 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 50POS 0.100
...
| Part | Card Type | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Mounting Type | Contact Type | Number of Positions | Number of Positions/Bay/Row [custom] | Termination | Termination Rows | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Contact Finish | Read Out | Pitch [x] | Pitch [x] | Gender | Material - Insulation | Color | Contact Material | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 3.96 mm | Flush Mount Top Opening Unthreaded | 0.156 in | Through Hole Right Angle | Cantilever | 50 | 50 | Solder Wire Wrap | 1 | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | 1 | Gold | Single | 2.54 mm | 0.1 in | Female | Polyester Thermoplastic | Green | Copper Alloy | |
 EDAC Inc. | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole | Cantilever | 50 | 50 | Wire Wrap | 1 | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | 1 | Gold | Single | 2.54 mm | 0.1 in | Female | Polyester Thermoplastic | Green | Copper Alloy | ||||
 EDAC Inc. | Non Specified - Dual Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.95 mm | Floating Bobbin Flush Mount | 0.116 in | Board Edge Straddle Mount | Cantilever | 50 | 25 | Solder Eyelet(s) | 2 | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | 2 | Gold | Dual | 2.54 mm | 0.1 in | Female | Polyester Thermoplastic | Green | Copper Alloy | Card Extender |
 EDAC Inc. | Non Specified - Dual Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 4-40 Flush Mount Threaded Insert Top Opening | Board Edge Straddle Mount | Cantilever | 50 | 25 | Solder | 2 | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | 2 | Gold | Dual | 2.54 mm | 0.1 in | Female | Polyester Thermoplastic | Green | Copper Alloy | Card Extender | ||
 EDAC Inc. | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Cantilever | 50 | 50 | Solder | 1 | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | 1 | Gold | Single | 2.54 mm | 0.1 in | Female | Polyester Thermoplastic | Green | Copper Alloy | |||
 EDAC Inc. | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.95 mm | Floating Bobbin Flush Mount | 0.116 in | Through Hole | Cantilever | 50 | 50 | Solder Eyelet(s) | 1 | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | 1 | Gold | Single | 2.54 mm | 0.1 in | Female | Polyester Thermoplastic | Green | Copper Alloy | |
 EDAC Inc. | Non Specified - Dual Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | Through Hole Right Angle | Cantilever | 50 | 25 | Solder Wire Wrap | 2 | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | 2 | Gold | Dual | 2.54 mm | 0.1 in | Female | Polyester Thermoplastic | Green | Copper Alloy | |
 EDAC Inc. | Non Specified - Dual Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Flush Mount M3 Threaded Insert Top Opening | Through Hole | Cantilever | 50 | 25 | Wire Wrap | 2 | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | 2 | Gold | Dual | 2.54 mm | 0.1 in | Female | Polyester Thermoplastic | Green | Copper Alloy | |||
 EDAC Inc. | Non Specified - Dual Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.95 mm | Floating Bobbin Flush Mount | 0.116 in | Through Hole | Cantilever | 50 | 25 | Solder | 2 | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | 2 | Gold | Dual | 2.54 mm | 0.1 in | Female | Polyester Thermoplastic | Green | Copper Alloy | |
 EDAC Inc. | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Through Hole | Cantilever | 50 | 50 | Solder | 1 | -40 °C | 105 ░C | 10 Áin | 0.25 Ám | 1 | Gold | Single | 2.54 mm | 0.1 in | Female | Polyester Thermoplastic | Green | Copper Alloy |
