83002 Series

Catalog

WIRE, HOOK UP, HI TEMP, PTFE, WHITE, 26 AWG, 100 FT

Part	Operating Temperature [Min]	Operating Temperature [Max]	Features	Length [x]	Length [x]	Qualification	Conductor Material	Jacket Color	Voltage	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Ratings	Jacket (Insulation) Material	Wire Gauge	Conductor Strand [x]	Conductor Strand [x]	Cable Type	Length	Length
Belden Inc. 83002 009100	-70 °C	200 °C	High Temperature	100 ft	30.5 m	MIL-W-16878/4	Copper Silver Coated	White	600 V	0.25 mm	0.01 in	0.99 mm	0.039 in	UL Style 1213	Tetrafluoroethylene (TFE)	26 AWG	34 AWG	7	Hook-Up
Belden Inc. 83002 002100	-70 °C	200 °C	High Temperature	100 ft	30.5 m	MIL-W-16878/4	Copper Silver Coated	Red	600 V	0.25 mm	0.01 in	0.99 mm	0.039 in	UL Style 1213	Tetrafluoroethylene (TFE)	26 AWG	34 AWG	7	Hook-Up
Belden Inc. 83002 003100	-70 °C	200 °C	High Temperature	100 ft	30.5 m	MIL-W-16878/4	Copper Silver Coated	Orange	600 V	0.25 mm	0.01 in	0.99 mm	0.039 in	UL Style 1213	Tetrafluoroethylene (TFE)	26 AWG	34 AWG	7	Hook-Up
Belden Inc. 83002 001100	-70 °C	200 °C	High Temperature	100 ft	30.5 m	MIL-W-16878/4	Copper Silver Coated	Brown	600 V	0.25 mm	0.01 in	0.99 mm	0.039 in	UL Style 1213	Tetrafluoroethylene (TFE)	26 AWG	34 AWG	7	Hook-Up
Belden Inc. 83002 0011000	-70 °C	200 °C	High Temperature			MIL-W-16878/4	Copper Silver Coated	Brown	600 V	0.25 mm	0.01 in	0.99 mm	0.039 in	UL Style 1213	Tetrafluoroethylene (TFE)	26 AWG	34 AWG	7	Hook-Up	304.8 m	1000 ft
Belden Inc. 83002 0021000	-70 °C	200 °C	High Temperature			MIL-W-16878/4	Copper Silver Coated	Red	600 V	0.25 mm	0.01 in	0.99 mm	0.039 in	UL Style 1213	Tetrafluoroethylene (TFE)	26 AWG	34 AWG	7	Hook-Up	304.8 m	1000 ft
Belden Inc. 83002 0031000	-70 °C	200 °C	High Temperature			MIL-W-16878/4	Copper Silver Coated	Orange	600 V	0.25 mm	0.01 in	0.99 mm	0.039 in	UL Style 1213	Tetrafluoroethylene (TFE)	26 AWG	34 AWG	7	Hook-Up	304.8 m	1000 ft
Belden Inc. 83002 0101000	-70 °C	200 °C	High Temperature			MIL-W-16878/4	Copper Silver Coated	Black	600 V	0.25 mm	0.01 in	0.99 mm	0.039 in	UL Style 1213	Tetrafluoroethylene (TFE)	26 AWG	34 AWG	7	Hook-Up	304.8 m	1000 ft
Belden Inc. 83002 008100	-70 °C	200 °C	High Temperature	100 ft	30.5 m	MIL-W-16878/4	Copper Silver Coated	Gray	600 V	0.25 mm	0.01 in	0.99 mm	0.039 in	UL Style 1213	Tetrafluoroethylene (TFE)	26 AWG	34 AWG	7	Hook-Up
