1486A Series
Manufacturer: Belden Inc.
Beta
⌘K
MULTI-PAIR 25COND 16/22AWG
| Part | Shield Coverage | Shield Material | Operating Temperature [Min] | Operating Temperature [Max] | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Features | Ratings | Jacket Color | Conductor Strand [y] | Conductor Strand [x] | Conductor Material | Cable Type | Wire Gauge | Shield Type | Conductor Insulation | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Voltage | Jacket (Insulation) Material | Usage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 100 % | Aluminum | -30 ░C | 105 ░C | 1.6 mm | 0.063 in | Drain Wire Rip Cord | UL Style 2464 | Black | 24 AWG 30 AWG | 7 | Copper Bare | Multi-Pair | 16 AWG 22 AWG | Foil | Poly-Vinyl Chloride (PVC) | 19.3 mm | 0.76 in | 300 VDC | Poly-Vinyl Chloride (PVC) | Instrumentation |
