S18UU Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
ULTRASONIC SENSOR, U-GAGE™ S18U SERIES, STRAIGHT, 300 MM, 0 TO 10 VDC, 10 TO 30 VDC, CABLE
| Part | Sensing Distance [Max] | Sensing Distance [Min] | Sensing Distance [Max] | Sensing Distance [Min] | Shielding | Indicator | Response Frequency | Ingress Protection | Material - Body | Package / Case | Sensor Type | Output Type | Operating Temperature [Min] | Operating Temperature [Max] | Termination Style | Voltage - Supply [Min] | Voltage - Supply [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | 300 mm | 30 mm | 11.811 " | 1.181 in | Unshielded | LED | 300 kHz | IP67 | Thermoplastic Polyester | Cylinder Threaded - M18 | Ultrasonic | Analog Voltage | -20 ░C | 60 °C | Cable | 10 VDC | 30 VDC |
