A-CCS 03 Series
Manufacturer: Assmann WSW Components
Beta
⌘K
IC PLCC SOCKET 32POS TIN SMD
| Part | Material Flammability Rating | Current Rating (Amps) | Contact Resistance | Housing Material | Features | Contact Material - Mating | Termination | Number of Positions or Pins (Grid) | Number of Positions or Pins (Grid) [y] | Number of Positions or Pins (Grid) [x] | Contact Finish - Post | Pitch - Post | Pitch - Post | Contact Material - Post | Mounting Type | Type | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Operating Temperature [Min] | Operating Temperature [Max] | Pitch - Mating | Pitch - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Assmann WSW Components | UL94 V-0 | 1 A | 15 mOhm | Glass Filled Nylon 9T Polyamide (PA9T) | Closed Frame | Phosphor Bronze | Solder | 32 | 7 9 | 2 | Tin | 0.05 in | 1.27 mm | Phosphor Bronze | Surface Mount | PLCC | 4.06 µm | 160 µin | -40 C | 105 ░C | 1.27 mm | 0.05 in |
