TPS2459 Series

3-V to 15-V hot swap controller with Oring and I2C

Catalog

3-V to 15-V hot swap controller with Oring and I2C

Part	Contents	Supplied Contents	Type	Utilized IC / Part	Applications	Package / Case	Voltage - Supply [Max]	Voltage - Supply [Min]	Mounting Type	Internal Switch(s)	Current - Output (Max)	Number of Channels [custom]	Operating Temperature [Max]	Operating Temperature [Min]	Features	Programmable Features	Supplier Device Package	Current - Supply
Texas Instruments TPS2459EVM	Board(s)	Board(s)	Power Management	TPS2459
Texas Instruments TPS2459RHBT			Hot Swap Controller OR Controller		ATCA MicroTCA™	32-VFQFN Exposed Pad	4 V 15 V	3 V 8.5 V	Surface Mount	Both	165 mA	2	85 °C	-40 °C	I2C Thermal Limit UVLO	Auto Retry Circuit Breaker Current Limit Fault Timeout Latched Fault Slew Rate	32-VQFN (5x5)	3.1 mA
Texas Instruments TPS2459RHBR			Hot Swap Controller OR Controller		ATCA MicroTCA™	32-VFQFN Exposed Pad	4 V 15 V	3 V 8.5 V	Surface Mount	Both	165 mA	2	85 °C	-40 °C	I2C Thermal Limit UVLO	Auto Retry Circuit Breaker Current Limit Fault Timeout Latched Fault Slew Rate	32-VQFN (5x5)	3.1 mA

Catalog

3-V to 15-V hot swap controller with Oring and I2C

Key Features

• ATCA AdvancedMC™ CompliantFull Power Control for an AdvancedMC™ ModuleIndependently Programmable 12-V Current Limit and Fast Trip3.3-V and 12-V FET ORing Control for MicroTCA12-V Output Shuts Off If 3.3-V Output Shuts OffInternal 3.3-V Current Limit and ORingI2C Power Good and Fault ReportingI2C™ Programmable Fault Times and LimitsFET Status Bits for 3.3-V and 12-V ChannelsLoad Current Monitors for 12-V and 3.3-V32-Pin QFN PackageATCA AdvancedMC™ CompliantFull Power Control for an AdvancedMC™ ModuleIndependently Programmable 12-V Current Limit and Fast Trip3.3-V and 12-V FET ORing Control for MicroTCA12-V Output Shuts Off If 3.3-V Output Shuts OffInternal 3.3-V Current Limit and ORingI2C Power Good and Fault ReportingI2C™ Programmable Fault Times and LimitsFET Status Bits for 3.3-V and 12-V ChannelsLoad Current Monitors for 12-V and 3.3-V32-Pin QFN Package

Description

The TPS2459 hot-plug controller performs all necessary power interface functions for an AdvancedMC™ (Advanced Mezzanine Card). A fully integrated 3.3-V channel provides inrush control, over-current protection, and FET ORing. A 12-V channel provides the same functions using external FETs and sense resistors. The 3.3-V current limit is factory set to AdvancedMC™ compliant levels while the 12-V current limit is programmed using external sense resistors. The accurate current sense comparators of the TPS2459 satisfy the narrow ATCA™ AdvancedMC™ current limit requirements. The TPS2459 hot-plug controller performs all necessary power interface functions for an AdvancedMC™ (Advanced Mezzanine Card). A fully integrated 3.3-V channel provides inrush control, over-current protection, and FET ORing. A 12-V channel provides the same functions using external FETs and sense resistors. The 3.3-V current limit is factory set to AdvancedMC™ compliant levels while the 12-V current limit is programmed using external sense resistors. The accurate current sense comparators of the TPS2459 satisfy the narrow ATCA™ AdvancedMC™ current limit requirements.
