887-013 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 13POS 0.156
| Part | Termination Rows | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Mounting Type | Number of Rows | Card Thickness [Max] | Card Thickness [Min] | Termination | Color | Read Out | Contact Finish | Contact Type | Flange Feature | Pitch | Pitch | Gender | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Card Type | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 13 | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Black | Single | Gold | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Female | 13 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Single Edge | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 13 | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Black | Single | Gold | Cantilever | Flush Mount M3 Threaded Insert Top Opening | 3.96 mm | 0.156 in | Female | 13 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Single Edge | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 13 | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Black | Single | Gold | Cantilever | 4-40 Threaded Insert Top Mount Opening | 3.96 mm | 0.156 in | Female | 13 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Single Edge | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 13 | Right Angle Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Black | Single | Gold | Cantilever | 3.96 mm | 0.156 in | Female | 13 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Single Edge | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 13 | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Black | Single | Gold | Cantilever | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | Female | 13 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Single Edge | 0.156 " | 3.96 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 13 | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Black | Single | Gold | Cantilever | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | Female | 13 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Single Edge | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 13 | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Black | Single | Gold | Cantilever | Flush Mount M3 Threaded Insert Top Opening | 3.96 mm | 0.156 in | Female | 13 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Single Edge | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 13 | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Black | Single | Gold | Cantilever | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | Female | 13 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Single Edge | 0.156 " | 3.96 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 13 | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Black | Single | Gold | Cantilever | M3 Threaded Insert Top Mount Opening | 3.96 mm | 0.156 in | Female | 13 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Single Edge | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | 13 | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Black | Single | Gold | Cantilever | Floating Bobbin Flush Mount | 3.96 mm | 0.156 in | Female | 13 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Single Edge | 0.116 " | 2.95 mm |
