103336 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

03 MODII HDR SRST UNSHRD A/PIN

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Termination	Insulation Height [z]	Insulation Height [z]	Contact Shape	Number of Positions Loaded	Overall Contact Length	Overall Contact Length	Contact Material	Fastening Type	Shrouding	Contact Length - Mating	Contact Length - Mating	Material Flammability Rating	Number of Rows	Contact Type	Pitch - Mating	Pitch - Mating	Insulation Color	Style	Connector Type	Contact Length - Post	Contact Length - Post	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Post	Contact Finish - Mating	Mounting Type	Insulation Material	Number of Positions
TE Connectivity AMP Connectors 4-103336-0	2.54 µm	100 µin	0.76 Ám	30 Áin	Press-Fit Solder	0.09 in	2.29 mm	Square	All	0.66 in	16.76 mm	Copper Alloy	Push-Pull	Unshrouded	0.32 in	8.13 mm	UL94 V-0	1	Male Pin	0.1 "	2.54 mm	Black	Board to Board Cable	Header	6.35 mm	0.25 in	3 A	-55 C	125 °C	Tin-Lead	Gold	Through Hole	Thermoplastic
TE Connectivity AMP Connectors 103336-9	2.54 µm	100 µin	0.76 Ám	30 Áin	Press-Fit Solder	0.09 in	2.29 mm	Square	All	0.66 in	16.76 mm	Copper Alloy	Push-Pull	Unshrouded	0.32 in	8.13 mm	UL94 V-0	1	Male Pin	0.1 "	2.54 mm	Black	Board to Board Cable	Header	6.35 mm	0.25 in	3 A	-55 C	125 °C	Tin-Lead	Gold	Through Hole	Thermoplastic	16
TE Connectivity AMP Connectors 3-103336-6	2.54 µm	100 µin	0.76 Ám	30 Áin	Press-Fit Solder	0.09 in	2.29 mm	Square	All	0.66 in	16.76 mm	Copper Alloy	Push-Pull	Unshrouded	0.32 in	8.13 mm	UL94 V-0	1	Male Pin	0.1 "	2.54 mm	Black	Board to Board Cable	Header	6.35 mm	0.25 in	3 A	-55 C	125 °C	Tin-Lead	Gold	Through Hole	Thermoplastic	4
TE Connectivity AMP Connectors 103336-6	2.54 µm	100 µin	0.76 Ám	30 Áin	Press-Fit Solder	0.09 in	2.29 mm	Square	All	0.66 in	16.76 mm	Copper Alloy	Push-Pull	Unshrouded	0.32 in	8.13 mm	UL94 V-0	1	Male Pin	0.1 "	2.54 mm	Black	Board to Board Cable	Header	6.35 mm	0.25 in	3 A	-55 C	125 °C	Tin-Lead	Gold	Through Hole	Thermoplastic	13
TE Connectivity AMP Connectors 8-103336-3	2.54 µm	100 µin	0.76 Ám	30 Áin	Press-Fit Solder	0.09 in	2.29 mm	Square	All	0.66 in	16.76 mm	Copper Alloy	Push-Pull	Unshrouded	0.32 in	8.13 mm	UL94 V-0	1	Male Pin	0.1 "	2.54 mm	Black	Board to Board Cable	Header	6.35 mm	0.25 in	3 A	-55 C	125 °C	Tin	Gold	Through Hole	Thermoplastic	40
TE Connectivity AMP Connectors 3-103336-8	2.54 µm	100 µin	0.76 Ám	30 Áin	Press-Fit Solder	0.09 in	2.29 mm	Square	All	0.66 in	16.76 mm	Copper Alloy	Push-Pull	Unshrouded	0.32 in	8.13 mm	UL94 V-0	1	Male Pin	0.1 "	2.54 mm	Black	Board to Board Cable	Header	6.35 mm	0.25 in	3 A	-55 C	125 °C	Tin-Lead	Gold	Through Hole	Thermoplastic	5
TE Connectivity AMP Connectors 3-103336-4	2.54 µm	100 µin	0.76 Ám	30 Áin	Press-Fit Solder	0.09 in	2.29 mm	Square	All	0.66 in	16.76 mm	Copper Alloy	Push-Pull	Unshrouded	0.32 in	8.13 mm	UL94 V-0	1	Male Pin	0.1 "	2.54 mm	Black	Board to Board Cable	Header	6.35 mm	0.25 in	3 A	-55 C	125 °C	Tin-Lead	Gold	Through Hole	Thermoplastic	2
TE Connectivity AMP Connectors 3-103336-7	2.54 µm	100 µin	0.76 Ám	30 Áin	Press-Fit Solder	0.09 in	2.29 mm	Square	All	0.66 in	16.76 mm	Copper Alloy	Push-Pull	Unshrouded	0.32 in	8.13 mm	UL94 V-0	1	Male Pin	0.1 "	2.54 mm	Black	Board to Board Cable	Header	6.35 mm	0.25 in	3 A	-55 C	125 °C	Tin-Lead	Gold	Through Hole	Thermoplastic	6
TE Connectivity AMP Connectors 5-103336-9	2.54 µm	100 µin	0.76 Ám	30 Áin	Press-Fit Solder	0.09 in	2.29 mm	Square	All	0.66 in	16.76 mm	Copper Alloy	Push-Pull	Unshrouded	0.32 in	8.13 mm	UL94 V-0	1	Male Pin	0.1 "	2.54 mm	Black	Board to Board Cable	Header	6.35 mm	0.25 in	3 A	-55 C	125 °C	Tin	Gold	Through Hole	Thermoplastic	16
TE Connectivity AMP Connectors 1-103336-3	2.54 µm	100 µin	0.76 Ám	30 Áin	Press-Fit Solder	0.09 in	2.29 mm	Square	All	0.66 in	16.76 mm	Copper Alloy	Push-Pull	Unshrouded	0.32 in	8.13 mm	UL94 V-0	1	Male Pin	0.1 "	2.54 mm	Black	Board to Board Cable	Header	6.35 mm	0.25 in	3 A	-55 C	125 °C	Tin-Lead	Gold	Through Hole	Thermoplastic	20
