DD12.4121 Series
Manufacturer: SCHURTER Inc.
Beta
⌘K
PWR ENT MOD RCPT IEC320-C14 PNL
| Part | Filter Type | Accomodates a Fuse | Approval Agency | Panel Cutout Dimensions [x] | Panel Cutout Dimensions [y] | Current Rating - Appliance Inlet | Features | Ingress Protection | Switch Features | Connector Style | Voltage Rating - Appliance Inlet | Panel Thickness [Max] | Panel Thickness [Max] | Panel Thickness [Min] | Panel Thickness [Min] | Material Flammability Rating | Current Rating - Filter | Mounting Type | Termination | Termination | Termination | Fuse Holder, Drawer | Connector Type | Panel Thickness | Panel Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | Filtered (EMI RFI) - Commercial | cURus ENEC | 29.8 mm | 49.3 mm | 10 A | Earth Line Choke Shielded V-Lock Notch | IP40 | Switch On-Off | IEC 320-C14 | 250 VAC | 0.118 in | 3 mm | 1 mm | 0.039 in | UL94 V-0 | 4 A | Panel Mount Snap-In | 6.3 mm | Quick Connect | 0.25 " | Drawer Sold Separate | Receptacle Male Blades - Module | |||
SCHURTER Inc. | Filtered (EMI RFI) - Commercial | cURus ENEC | 29.8 mm | 49.3 mm | 10 A | Earth Line Choke Shielded V-Lock Notch | IP40 | Switch On-Off | IEC 320-C14 | 250 VAC | UL94 V-0 | 4 A | Flange Panel Mount | 6.3 mm | Quick Connect | 0.25 " | Drawer Sold Separate | Receptacle Male Blades - Module | 8 mm | 0.315 in |
