183-037 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB RCPT 37POS R/A SLDR
| Part | Color | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Mounting Type | Contact Finish | Connector Style | Material Flammability Rating | Contact Type | Current Rating (Amps) | Contact Finish Thickness | Flange Feature | Number of Rows [custom] | Shell Size, Connector Layout | Shell Size, Connector Layout | Number of Positions | Features | Connector Type | Backset Spacing | Backset Spacing | Contact Material | Shell Material, Finish | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Black | Polyester Glass Filled | -55 C | 105 ░C | Solder | Panel Mount Right Angle Through Hole | Gold | D-Sub | UL94 V-0 | Signal | 5 A | Flash | Housing/Shell (Unthreaded) | 2 | 4 | DC C | 37 | Ground Strap | Receptacle Female Sockets | 0.59 in | 14.99 mm | |||
 NorComp Inc. | Black | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Solder | Panel Mount Right Angle Through Hole | Gold | D-Sub | UL94 V-0 | Signal | 5 A | Flash | 4-40 Mating Side Female Screwlock | 2 | 4 | DC C | 37 | Receptacle Female Sockets | 0.59 in | 14.99 mm | Brass | Nickel Plated Steel | ||
NorComp Inc. | Black | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Solder | Panel Mount Right Angle Through Hole | Gold | D-Sub | UL94 V-0 | Signal | 5 A | Flash | Housing/Shell (Unthreaded) | 2 | 4 | DC C | 37 | Grounding Indents | Plug Male Pins | 0.59 in | 14.99 mm | Brass | Nickel Plated Steel | |
NorComp Inc. | Black | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Solder | Panel Mount Right Angle Through Hole | Gold | D-Sub | UL94 V-0 | Signal | 5 A | Flash | Housing/Shell | 2 | 4 | DC C | 37 | Grounding Indents | Plug Male Pins | 0.59 in | 14.99 mm | Brass | Nickel Plated Steel | 4-40 |
 NorComp Inc. | Black | Polyester Glass Filled | -55 C | 105 ░C | Solder | Panel Mount Right Angle Through Hole | Gold | D-Sub | UL94 V-0 | Signal | 5 A | Flash | Housing/Shell (Unthreaded) | 2 | 4 | DC C | 37 | Ground Strap Grounding Indents | Plug Male Pins | 0.59 in | 14.99 mm | |||
 NorComp Inc. | Black | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Solder | Panel Mount Right Angle Through Hole | Gold | D-Sub | UL94 V-0 | Signal | 5 A | Flash | Housing/Shell | 2 | 4 | DC C | 37 | Ground Strap | Receptacle Female Sockets | 0.59 in | 14.99 mm | Brass | Nickel Plated Steel | 4-40 |
NorComp Inc. | Black | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Solder | Panel Mount Right Angle Through Hole | Gold | D-Sub | UL94 V-0 | Signal | 5 A | Flash | Housing/Shell | 2 | 4 | DC C | 37 | Receptacle Female Sockets | 0.59 in | 14.99 mm | Brass | Nickel Plated Steel | 4-40 | |
 NorComp Inc. | Black | Polyester Glass Filled | -55 C | 105 ░C | Solder | Panel Mount Right Angle Through Hole | Gold | D-Sub | UL94 V-0 | Signal | 5 A | Flash | Housing/Shell | 2 | 4 | DC C | 37 | Board Lock | Receptacle Female Sockets | 0.59 in | 14.99 mm | 4-40 | ||
NorComp Inc. | Black | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Solder | Panel Mount Right Angle Through Hole | Gold | D-Sub | UL94 V-0 | Signal | 5 A | Flash | Housing/Shell (Unthreaded) | 2 | 4 | DC C | 37 | Receptacle Female Sockets | 0.59 in | 14.99 mm | Brass | Nickel Plated Steel | ||
NorComp Inc. | Black | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Solder | Panel Mount Right Angle Through Hole | Gold | D-Sub | UL94 V-0 | Signal | 5 A | Flash | Housing/Shell (Unthreaded) | 2 | 4 | DC C | 37 | Ground Strap | Receptacle Female Sockets | 0.59 in | 14.99 mm | Brass | Nickel Plated Steel |
