AEV250 Series
Manufacturer: Altran Magnetics, LLC
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
DC CONTACTOR 500A 12-24VDC AUX
| Part | Operate Time | Coil Current | Release Time | Contact Form | Contact Rating (Current) | Mounting Type | Termination Style | Switching Voltage DC (Max) | Must Operate Voltage | Must Release Voltage | Coil Voltage (Min) | Coil Voltage (Max) | Operating Temperature (Min) | Operating Temperature (Max) | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Altran Magnetics, LLC | 25 ms | 130 mA | 12 ms | 1 DM Form SPST-NO X | 500 A | Chassis Mount | Stud Wire Leads | 1000 VDC | 9 VDC | 6 VDC | 12 VAC/DC | 24 VAC/DC | -40 °C | 85 °C | Auxiliary Contacts Economizer Hermetically Sealed |
Altran Magnetics, LLC | 25 ms | 130 mA | 12 ms | 1 DM Form SPST-NO X | 500 A | Chassis Mount | Stud Wire Leads | 1000 VDC | 9 VDC | 6 VDC | 12 VAC/DC | 24 VAC/DC | -40 °C | 85 °C | Economizer Hermetically Sealed |
