DDM50 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN D-SUB RCPT 50POS R/A SOLDER
| Part | Termination | Connector Type | Voltage Rating | Dielectric Material | Backset Spacing | Backset Spacing | Number of Positions | Material Flammability Rating | Contact Type | Connector Style | Contact Material | Number of Rows | Current Rating (Amps) | Flange Feature | Mounting Type | Shell Material, Finish | Shell Size, Connector Layout | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Features | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol ICC (FCI) | Solder | Receptacle Female Sockets | 300 VDC | Thermoplastic | 0.406 in | 10.3 mm | 50 | UL94 V-0 | Signal | D-Sub | Brass | 3 | 7.5 A | Housing/Shell (Unthreaded) | Through Hole Right Angle | Steel Yellow Cadmium Plated | 5 | 155 °C | -55 °C | Gold | |||
Amphenol ICC (FCI) | Solder | Male Pins Plug | 300 VDC | Thermoplastic Glass Filled | 0.283 in | 7.2 mm | 50 | UL94 V-0 | Signal | D-Sub | Phosphor Bronze | 3 | 7.5 A | Housing/Shell (Unthreaded) | Through Hole Right Angle | Steel Yellow Cadmium Plated | 5 | 155 °C | -55 °C | Gold | Mounting Brackets | ||
Amphenol ICC (FCI) | Solder | Male Pins Plug | 300 VDC | Thermoplastic | 0.406 in | 10.3 mm | 50 | UL94 V-0 | Signal | D-Sub | Phosphor Bronze | 3 | 7.5 A | Housing/Shell (Unthreaded) | Through Hole Right Angle | Steel Yellow Cadmium Plated | 5 | 155 °C | -55 °C | Gold | Mounting Brackets | 50 µin | 1.27 µm |
 Amphenol ICC (FCI) | Solder | Male Pins Plug | 300 VDC | Thermoplastic | 0.406 in | 10.3 mm | 50 | UL94 V-0 | Signal | D-Sub | Brass | 3 | 7.5 A | Housing/Shell (Unthreaded) | Through Hole Right Angle | Steel Yellow Cadmium Plated | 5 | 125 °C | -55 °C | Gold | |||
 Amphenol ICC (FCI) | Receptacle Female Sockets | 300 VDC | Thermoplastic | 50 | UL94 V-0 | Signal | D-Sub | Brass | 3 | 7.5 A | Housing/Shell (Unthreaded) | Free Hanging (In-Line) | Steel Yellow Cadmium Plated | 5 | 125 °C | -55 °C | Gold | ||||||
Amphenol ICC (FCI) | Solder | Receptacle Female Sockets | 300 VDC | Thermoplastic | 0.318 " | 8.08 mm | 50 | UL94 V-0 | Signal | D-Sub | Phosphor Bronze | 3 | 7.5 A | Housing/Shell (Unthreaded) | Through Hole Right Angle | Steel Yellow Cadmium Plated | 5 | 155 °C | -55 °C | Gold | 50 µin | 1.27 µm | |
 Amphenol ICC (FCI) | Male Pins Plug | 300 VDC | Thermoplastic | 50 | UL94 V-0 | Signal | D-Sub | Brass | 3 | 7.5 A | Housing/Shell (Unthreaded) | Free Hanging (In-Line) | Steel Yellow Cadmium Plated | 5 | 125 °C | -55 °C | Gold | ||||||
Amphenol ICC (FCI) | Solder | Receptacle Female Sockets | 300 VDC | Thermoplastic | 0.406 in | 10.3 mm | 50 | UL94 V-0 | Signal | D-Sub | Phosphor Bronze | 3 | 7.5 A | Housing/Shell (Unthreaded) | Through Hole Right Angle | Steel Yellow Cadmium Plated | 5 | 125 °C | -55 °C | Gold | |||
Amphenol ICC (FCI) | Solder | Receptacle Female Sockets | 300 VDC | Thermoplastic | 0.406 in | 10.3 mm | 50 | UL94 V-0 | Signal | D-Sub | Phosphor Bronze | 3 | 7.5 A | Housing/Shell (Unthreaded) | Through Hole Right Angle | Steel Yellow Cadmium Plated | 5 | 155 °C | -55 °C | Gold | Mounting Brackets | ||
Amphenol ICC (FCI) | Wire Wrap | Male Pins Plug | 300 VDC | Thermoplastic | 50 | UL94 V-0 | Signal | D-Sub | Brass | 3 | 7.5 A | Housing/Shell (Unthreaded) | Panel Mount Through Hole | Steel Yellow Cadmium Plated | 5 | 125 °C | -55 °C | Gold |
