SI86SO2 Series

Catalog

DIGITAL ISOLATOR CMOS 2-CH 150MBPS 8-PIN SOIC N TUBE AUTOMOTIVE AEC-Q100

Part	Technology	Supplier Device Package	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Package / Case	Package / Case	Package / Case	Pulse Width Distortion (Max) [Max]	Voltage - Isolation	Common Mode Transient Immunity (Min) [Min]	Type	Channel Type	Mounting Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Number of Channels	Inputs - Side 1/Side 2 [custom]	Inputs - Side 1/Side 2 [custom]	Propagation Delay tpLH / tpHL (Max) [custom]	Propagation Delay tpLH / tpHL (Max) [custom]	Operating Temperature [Max]	Operating Temperature [Min]	Data Rate	Inputs - Side 1/Side 2	Qualification	Grade
Skyworks Solutions Inc. SI86SO20BC-IS	Capacitive Coupling	8-SOIC	2.5 ns	2.5 ns	0.154 in	8-SOIC	3.9 mm	2.5 ns	3750 Vrms	150 kV/µs	General Purpose	Unidirectional	Surface Mount	2.25 V	5.5 V	2	2	0	13.5 ns	13.5 ns	125 °C	-40 C	150 Mbps
Skyworks Solutions Inc. SI86SO21EE-AS4R	Capacitive Coupling	8-SSO	2.5 ns	2.5 ns		8-SOIC (0.295" 7.50mm Width)		2.5 ns	6000 Vrms	150 kV/µs	General Purpose	Unidirectional	Surface Mount	2.25 V	5.5 V	2			13.5 ns	13.5 ns	125 °C	-40 C	150 Mbps	1	AEC-Q100	Automotive
Skyworks Solutions Inc. SI86SO21BC-AS	Capacitive Coupling	8-SOIC	2.5 ns	2.5 ns	0.154 in	8-SOIC	3.9 mm	2.5 ns	3750 Vrms	150 kV/µs	General Purpose	Unidirectional	Surface Mount	2.25 V	5.5 V	2			13.5 ns	13.5 ns	125 °C	-40 C	150 Mbps	1	AEC-Q100	Automotive
Skyworks Solutions Inc. SI86SO20BC-ISR	Capacitive Coupling	8-SOIC	2.5 ns	2.5 ns	0.154 in	8-SOIC	3.9 mm	2.5 ns	3750 Vrms	150 kV/µs	General Purpose	Unidirectional	Surface Mount	2.25 V	5.5 V	2	2	0	13.5 ns	13.5 ns	125 °C	-40 C	150 Mbps
Skyworks Solutions Inc. SI86SO20EC-AS	Capacitive Coupling	8-SOIC	2.5 ns	2.5 ns	0.154 in	8-SOIC	3.9 mm	2.5 ns	3750 Vrms	150 kV/µs	General Purpose	Unidirectional	Surface Mount	2.25 V	5.5 V	2	2	0	13.5 ns	13.5 ns	125 °C	-40 C	150 Mbps		AEC-Q100	Automotive
Skyworks Solutions Inc. SI86SO20BE-AS4R	Capacitive Coupling	8-SSO	2.5 ns	2.5 ns		8-SOIC (0.295" 7.50mm Width)		2.5 ns	6000 Vrms	150 kV/µs	General Purpose	Unidirectional	Surface Mount	2.25 V	5.5 V	2	2	0	13.5 ns	13.5 ns	125 °C	-40 C	150 Mbps		AEC-Q100	Automotive
Skyworks Solutions Inc. SI86SO21EC-ASR	Capacitive Coupling	8-SOIC	2.5 ns	2.5 ns	0.154 in	8-SOIC	3.9 mm	2.5 ns	3750 Vrms	150 kV/µs	General Purpose	Unidirectional	Surface Mount	2.25 V	5.5 V	2			13.5 ns	13.5 ns	125 °C	-40 C	150 Mbps	1	AEC-Q100	Automotive
Skyworks Solutions Inc. SI86SO20EE-AS4R	Capacitive Coupling	8-SSO	2.5 ns	2.5 ns		8-SOIC (0.295" 7.50mm Width)		2.5 ns	6000 Vrms	150 kV/µs	General Purpose	Unidirectional	Surface Mount	2.25 V	5.5 V	2	2	0	13.5 ns	13.5 ns	125 °C	-40 C	150 Mbps		AEC-Q100	Automotive
Skyworks Solutions Inc. SI86SO21BC-IS	Capacitive Coupling	8-SOIC	2.5 ns	2.5 ns	0.154 in	8-SOIC	3.9 mm	2.5 ns	3750 Vrms	150 kV/µs	General Purpose	Unidirectional	Surface Mount	2.25 V	5.5 V	2			13.5 ns	13.5 ns	125 °C	-40 C	150 Mbps	1
Skyworks Solutions Inc. SI86SO20EC-IS	Capacitive Coupling	8-SOIC	2.5 ns	2.5 ns	0.154 in	8-SOIC	3.9 mm	2.5 ns	3750 Vrms	150 kV/µs	General Purpose	Unidirectional	Surface Mount	2.25 V	5.5 V	2	2	0	13.5 ns	13.5 ns	125 °C	-40 C	150 Mbps
